Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of dongfeng 8m3 rear loader garbage truck in China. If you're going to buy high quality dongfeng 8m3 rear loader garbage truck, welcome to get more information from our factory. For price consultation, contact us.
Dongfeng 8cbm rear loader garbage truck(also called 8m3 garbage compactor truck,6 tons garbage compactor truck,8m3 garbage truck,6tons compactor garbage truck,compactor garbage truck,refuse compactor truck,rear loading garbage truck,waste truck,waste recycling truck,disposal truck) is suitable for waste management companies which using for city garbage collection,recycling & transport, the loaded garbage can be compressed and crushed to increase the density and reduce the volume, which greatly improves the efficiency of garbage collection and transportation. Garbage truck from CLW group hubei chengli special automobile co., ltd is with advantage of reliable quality, low failure rate, convenient maintenance and low operating cost.
Why do you choose CLW group for garbage trucks?
Top 3 sale in China for many years in garbage trucks
Chinese top brand oil cylinders;
British DLI seal ring;
Chinese top brand multi-way valves;
Chinese top brand hydraulic oil pump;
Compensates misalignment and deflections;
PLC or CAN operation contral model for option;
Capable to deliver batch order in short time;
Brand New, 4X2 Drive,small&mobile chassis;
No overhaul within 100,000 km;
English Manual( Other language is available);
Two-way compression and the loading efficiency is high;
Optional post-installation monitoring system is convenient
to realize visual loading and unloading operations in the cab;
Double insurance system, the operation system has dual
functions of automatic control and manual operation,
which greatly guarantees and improves the utilization rate of the vehicle.
Driving Model | 4 X 2 | |
Cab | Left/right Hand Driving 2 passengers, with air condition | |
Wheel Base | 3800mm | |
Loading Weight | 1730kg | |
Curb Weight | 6350kg | |
Axle Loading (front/rear) | 3300/4975 kg | |
External Dimensions (L x W x H) | 7350*2250*2750mm | |
Overhang (front/rear) | 1150/2410mm | |
Wheel track (front/rear) | 1740 /1610mm | |
Approach/Departure angle | 20°/ 12° | |
Max. driving speed | 95 km/h | |
Engine | Model | YC4FA120-33 |
Type | 4-cylinders in a line, turbo-charging and inter-cooling | |
Horse Power | 120 Hp | |
Max output power | 88kW | |
Emission standard | Euro III | |
Displacement | 3856ml | |
Rated Speed | 3800rpm | |
Gearbox | 6 forwards & 1 reverse | |
Clutch | Reinforced diaphragm clutch | |
Tire | 7.50R16, 6 pieces with 1 spare tire. | |
Tanker body material | Quality high tensile Q345 carbon steel |
Shape | rectangular box, arc-shaped rear |
Thickness | Side 4mm, Bottom 4mm |
Garbage Container Size | 8 CBM |
Max. Loading Capacity | 100 Barrels (240L) |
Equipment | ◆ Equipped with triangle waste collection bin; ◆ oil cylinder and Hefei Changyuan whole set of hydraulic system(multi-way valve and gear pump) and operating system. ◆ Automatic bi-directional compression; ◆ Double sewage collection boxes at rear and side of truck ◆ rear seal rubber blanket to avoid sewage leaking ◆ SPLC flashlight integrated operation model. ◆ Operate in cabin and also both sides of rear truck. ◆ Equipped with garbage bucket flip plate |
Pre sale service
--- Technical communication with engineer --- Factory and workshop visit --- Designed drawings
After Sale Service --- Overseas installation and commissioning --- Overseas and spare parts support --- Technical and spare parts support
Truck According to your request, choose good chassis and refit it to truck.
Upper Body Supply only upper body without chassis. According to your chassis drawing,design function parts.
Customization Communicate with engineer,making drawings and produce customized products.
Spare Parts Supply all kinds of spare parts on chassis and upper body,replace main parts on trucks as tank and box. |
FAQ
Q1: What kinds of garbage trucks I can order from your company?
A: There are various sizes and types of garbage trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.
Q2:: Have you supplied garbage truck to any overseas companies?
A: Yes,with need of garbage waste transport,we offered garbage trucks to many Africa and south-east Asian countries.
Q3 What about warranty?
A: Warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the truck has been delivered, whichever comes first.
Q4: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
