Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of 4x4 airport rescue fire truck in China. If you're going to buy high quality 4x4 airport rescue fire truck, welcome to get more information from our factory. For price consultation, contact us.
Product Description
Fire truck is also called as the fire fighting truck and fire engine. It is used to fight fire or for other emergency rescuing specially. For functions, it is divided into several kinds, including Pump truck, Ladder truck, and other trucks with some special equipment. The fire truck is usually kept in fire bureau, and is driven to the accident location by the fire fighter. Most fire trucks are painted in red, but still some rare places that is painted in yellow. The siren is usually taken as the standard device for the truck. In fact, fire truck is the common name for the truck that is equipped with various fire fighting devices and tools. It is the main equipment in fire fighting area and is the basic mobile fire fighting equipments.
Specification
|
Model |
Parameters |
others |
|
Overall Dimension |
8470×2500×3640mm |
|
|
GVW |
16000kg |
|
|
Engine Model |
WD615.87 |
|
|
Engine Power |
213kW/290hp |
|
|
Wheelbase |
4600mm |
|
|
Driving Type |
4×4 |
|
|
Max.speed |
100km/h |
|
|
Emission Standard |
5900ml |
Euro 2 |
|
Passengers |
2+3 |
|
|
Fire pump rated flow |
60L/s@1.0Mpa |
Vacuum pump |
|
water monitor rated flow |
60L/s@1.0MPa |
|
|
Water monitor range |
Water range≥55m |
|
|
Approach angle |
≥19° |
|
|
Departure angle |
≥13° |
Fire performance parameters:
|
Item Parameters |
Parameters |
others |
|||
|
1 |
Water tank capacity |
water |
3000kg |
Built-in type |
|
|
2 |
Fire pump model |
CB10/60 |
|
||
|
3 |
Fire pump performance |
60L/s@1.0MPa |
Use vacuum pump to priming water |
||
|
4 |
the installation site of fire pump |
rear |
|
||
|
5 |
The quantity of fire pump water outlet |
2 |
|
||
|
6 |
Pressure gauge |
0-1.6 Mpa |
2.6 level |
||
|
7 |
Vacuum gauge |
-0.1- -1 MPa |
2.6 level |
||
|
8 |
Water monitor |
Injection pressure |
water:≥55m |
|
|
|
1.0Mpa |
|||||
|
Depression/Elevation angle |
-15°~+60° |
||||
|
Turning angle 360° |
|||||
|
9 |
PTO Model |
YTQ200 (12V), MOTOR |
|
||
Fire Truck Production
Bulk Order for Fire Truck
Fire Truck bulk order Shipment
Overseas Exhibition and Local Support
Customer Visiting
Sales Service
1. One year quality warranty for key parts such as axles, engine, transmission;
2. All spare parts would be OEM and supplied at cost prices;
3. Regular phone call to collect information about the vehicle's working status and feedback from customers.
FAQ
Q: How about the warranty?
A: One year.
Q: Do you have ISO certificate ?
A: Yes , we have,please contact us to get our certificates.
Q: How about the delivery time?
A: Most of our trucks have stock ,we can deliver to you within 7 days, if specially ordered , normally we need around 30 days for production.
Q: How many units of truck does your factory produce per year?
A: Almost 3000 units.Nearly 300units per month.
Q: How do you control the quality of product?
A: Our Factory has standard production workshop,gets ISO CCC BV certificates,our workers are well trained. Every unit of product undergoes a rigorous inspection process.
Q: How about your product after-sales service system?
A: Our main export countries have accepted after-sales service,some countries use the third party service.
