Forland 3Tons ~4Tons Small Refuse Collection Garbage Compacting City Waste Delivery
Product Description
1. Garbage Compactor Truck change the dirty appearance of the city and eliminate the secondary pollution
2. Easy Full Automatic Operation: computer control system for loading and unloading operations.
Chassis configuration:
Foton Era small Star 3 chassis,
2850mm wheelbase, front-turning cab,
Full diesel 88 horsepower engine,
5-speed gearbox,
6.50R16 steel wire tires,
5 tons rear axle,
adjustable steering wheel,
Compacting System
Electronically controlled manual dual manipulators,
4 cubic fully sealed trash bins, dual control mechanisms for the cab and rear of the car,
A compression push plate inside the bin, which can compact the trash and increase the loading rate,
Compression ratio is 3-4 times, and the life after compression The garbage changes from 0.3 to 0.9 or more, the tailgate is hydraulically opened, and the push plate pushes out the garbage.
With a sewage collection box equipped with a turning bucket or hanging bucket device.
Specification Forland 3Tons ~4Tons Small Refuse Collection Garbage
Cabin | Driving type 4x2 | ||
With A/C. Left Hand Drive. | |||
Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 6220*2050*2570 | |
Wheel base (mm) | 3308 | ||
Wheel track (front/rear) (mm) | 1504/1425 | ||
Approach/Departure angle(°) | 24/16 | ||
Weight in KGS | Tare Weight | 5400 | |
Front axles loading capacity | 1800kg | ||
Rear axles loading capacity | 3500kg | ||
Max. driving speed(km/h) | 110 | ||
Engine | Brand | YUNEI | |
Type | 4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
Horse Power(HP) | 102 HP | ||
Emission standard | Euro III | ||
Gearbox | 5 forwards &1 reverse | ||
Clutch | Diaphragm spring clutch | ||
Steering Gear | Power steering | ||
Tire | 7.00R16 All radial tires with one spare, 7 pieces | ||
Compression garbage box body system | |||
Body Volume | 6m3 | ||
Material Thickness | 4mm | ||
Cycle Time of Filling(S) | ≤40 | ||
Lifting Time of Filler(S) | 8-10 | ||
Time of Discharging | ≤60 | ||
Working Pressure(MPA) | 16 | ||
Composed by hermetic garbage tank, hydraulic system, operation system. The entire truck is hermetic, can automatically compress and dump the garbage .and the sewage generated in the process of the compression all go into the sewage tank. | |||
