Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of 4x2 compactor garbage truck in China. If you're going to buy high quality 4x2 compactor garbage truck, welcome to get more information from our factory. For price consultation, contact us.
Product Description
1--Waste recycling truck is divided into compactor garbage truck, swing arm garbage truck, hook lift garbage truck, roll on roll off garbage truck, bin lift garbage truck, dumper garbage truck, sealed garbage truck,container garbage truck, rear load garbage truck and so on.
2--Easy Full Automatic Operation of waste recycling truck : computer control system for loading and unloading operations.
3--One Person Operation of waste recycling truck : Reducing sanitation working, greatly improves the working environment.
4--Double Operation System of waste recycling truck : computer control system and manual operation greatly improves the vehicle usage rate.
5--Capacity of waste recycling truck : option for 3-20m3 garbage truck.
6--Steering wheel of waste recycling truck : both left and right hand drive, meet the needs of different countries
7--Emission standard of waste recycling truck : option Euro 1,Euro 2,Euro 3,Euro 4, Euro 5 garbage truck
8--Truck chassis optional for waste recycling truck : option for japanese and chinese brand, such as dongfeng, isuzu, faw, foton, howo, jac, jmc, forland...
Specifications of dongfeng 4x2 compactor garbage truck
|
|
|||
|
Overall Dimension |
7100×2250×2750 mm |
Gross Vehicle Weight |
8275 kg |
|
Curb Weight |
6350 kg |
Loading Weight |
1730 kg |
|
Wheel Base |
3800 mm |
Front / Rear Axle |
2500 kg / 5000kg |
|
Cabin |
Left Hand Driving, 2 Passengers Allowed, with Air Conditioner, Radio, |
||
|
Engine |
Chaochai |
||
|
Engine horsepower |
156hp |
||
|
Max Driving Speed |
90 km/h |
||
|
Gear Box |
6 Forward Gear, 1 Reverse Gear, |
||
|
Tire |
7.50R16 (6 pieces with one spare) |
||
|
Garbage Bin |
Capacity |
8CBM |
|
|
Material |
4mm Carbon Steel for Garbage Bin Body |
||
|
Design |
Whole unit with Leakage Proof Design |
||
|
Ways of Loading |
Rear Loading with optional Bucket Lifting System |
||
|
Garbage Compact Ratio |
1/3 - 1/4 |
||
|
Control System |
One control Panel on the back, One Control system in back of Cabin |
||
|
Dispensing System |
1. Equipped with air-tight dustbin, hydraulic system and operating system. |
||
|
2. Automatic loading, compressing and discharging, all handled by 1 person |
|||
|
3. Sewage water collection tank to avoid any pollution during handling. |
|||
|
4. Large Pressure, Good Leakage Proof, Convenient Operation, Dependable Security |
|||
| 5. Electrical Control Panel for compacting system. | |||
|
6. Cycling time<14~18s |
|||
|
Remarks |
1. Color is optional |
||
|
2. Customized LOGO painting as per customer request |
|||
Truck Diagram
Product Details
Truck Details
Working Show
Exhibition and Local Support
Customer Visiting
Our warranty
1. One year quality guarantee for three key parts: Axles, engine, transmission.
2. Other spare part could be supplied by OEM at cost prices.
3. Regularly callback to know the vehicle's working status.
4. Experienced engineers are always ready to deal with unexpected needs.
Sales Service
1. We can product truck according the customer's requirements(color,size,logo and so on)
2. We can send our technician to arrive the customer's country to provide the service .
3. We can train customer's workers for free.
4. Our truck warranty:12 months.we can provide the parts for free at the first year.
FAQ
Q: Do you accept custom order? What’s is your MOQ order?
A: Yes, we do, our MOQ is 1 unit.
Q: What’s the payment terms?
A: By T/T bank transfer
Q: How about shipment?
A: 20FT container, 40FT container,40FT high container, open-top container,flat bed container ,Ro-Ro ship or bulk ship according to the size the products.
Q: How do you control the quality of product?
A: Our Factory has standard production workshop,gets ISO CCC BV certificates,our workers are well trained. Every unit of product undergoes a rigorous inspection process.
Q: How about your product after-sales service system?
A: Our main export countries have accepted after-sales service,some countries use the third party service.
