Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of HOWO 15 Tons Explosive Mixing Truck in China. If you're going to buy high quality HOWO 15 Tons Explosive Mixing Truck, welcome to get more information from our factory. For price consultation, contact us.
HOWO 350hp 8x4 15Tons On-Site Mixed Explosive Truck
Precision Mining, Any Terrain – The SINOTRUK HOWO Emulsion Series!
1.All-Terrain Chassis & Safety
The SINOTRUK HOWO 350HP 8x4 chassis offers superior off-road capability for complex mining roads. It runs entirely on the chassis engine without external power, featuring advanced safety interlocks, pressure sensors, and a secure guardrail platform for safe operation in demanding environments.
2. Intelligent Automated Operation
A PLC-based PID closed-loop control system maintains mixing tolerances within ±1%, ensuring precise explosive quality. The automatic hose management system, with a 2.3m radius, reduces labor to a single operator who can control hose retraction, hole-filling, and parameter recording directly from the cab.
3. Long-Distance Delivery & Adaptability
The unique water ring system enables high-viscosity emulsion delivery over 80 meters to distant boreholes. An optional fuel-powered heating system ensures winter operation, while the HMI allows instant adjustment of process ratios to match specific rock characteristics on-site.
Keywords:
SINOTRUK HOWO / 350HP 8x4 Chassis / Emulsion Explosive Truck / PID Closed-Loop Control / Automatic Hose Management / Long-Distance Delivery / Off-Road Mobility / Adjustable Process Ratios
Product Name: HOWO 8×4 Bulk Emulsion Truck
Application: On-site mixed explosive
Cab: One row and half cabin, LHD, A/C
Wheelbase: 1800+3800+1350 mm
Engine: WP8.350E61
Horsepower: 350HP
Emission standard: Euro VI
Gearbox: 12 Forwards and 2 reverse
Gross Vehicle Weight: 32000 kg
Curb weight: 1700 kg
Loading weight: 15000 kg
Front/Rear Axle loading: 9500kg /16000kg
Tires: 12R22.5, 12 pcs with one spare
|
Emulsion Explosive Tank |
|
|
Charging capacity |
15 Tons / 15,000kg |
|
Charging rate |
200–280 kg/min |
|
Tank material |
Stainless steel |
|
Tank thinkness |
5mm of tank and 6 mm of end plate |
|
Metering error |
< ±1% |
|
Control system |
|
|
PLC control box
|
|
|
Manual multi-way control valve
|
|
|
Pumping & Metering System |
|
|
Sensitizer metering pump
|
|
|
Water-ring lubrication pump
|
|
Intelligent all-terrain explosive delivery with automated precision control and adaptable process ratios!
HOWO TX 8×4 heavy-duty chassis
Remote central locking
ABS anti-lock braking
Rear air suspension
Equipped with AdBlue
Heavy-duty Air Cleaner
Suspension seat with adjustable height
360° rotating hose guide boom
Automatic hose handling system
Reduces labor intensity significantly
Composed of turntable, reel, and telescopic boom
2.3m operating radius for multi-directional loading
Automatic hose extension and retraction
Requires only one operator, improving efficiency
PLC electrical control system
HMI flowmeter and speed sensor
Closed-loop control for accelerator and sensitizer flow
Closed-loop control for emulsion matrix and additive mixing
PID closed-loop control for pump motor speed
Dosing accuracy maintained within ±1% error
Ensures precise explosive ratio and blasting performance
Customizable button labels in local languages
Manual-Auto Integrated Control
High-Precision Hydraulic Flow
Robust Reliability & Stability
Emergency Manual Override
Failure-Proof Operation System
Seamless Task Continuity
Dual-Mode Control Valve Bank
Special droplet-shaped tank
Water-drop shaped silo for better material flow
304 stainless steel with 50mm flame-retardant insulation
Enhanced strength and rigidity for rough terrain
Corrosion-resistant, fire-retardant, and anti-freeze
Professionally strength-calculated for durability
Advanced processing ensures long service life
Special water ring drag reduction system
Special water ring between pump and hose
Enables long-distance delivery of high-viscosity emulsion
Delivery pressure: 0.5–0.8MPa
Pumping distance up to 80 meters or more
Reduces pressure for same pipe diameter and flow
Allows multi-directional filling for hard-to-reach boreholes
Tank front
2pcs manhole
3pcs magnetic level gauges
Industrial thermometer
Hydraulic oil radiator
Explosion-proof electric box
Rear working platform
Tank ladder
Top guardrail
Anti-static
Warning light
Hose Reel with Guide Pulley
Emergency cut-off valve (on each side)
Anti-skid stainless steel walkway on tank top
MEMU End-sensitization Process Flow
The emulsification vehicle adopts end-point sensitization. The process flow is shown in the figure on the right:
Transportation of matrix and additives
When the truck arrives on site with emulsion matrix and additives.
Mixing & Pumping
Its integrated system pumps, mixes, and delivers the materials directly into the borehole.
sensitizes to the explosives
A water ring enables long-distance flow, while a static mixer ensures final blending, forming high-performance explosive in the hole.
