Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of sinotruk howo nx 10m³ water truck in China. If you're going to buy high quality sinotruk howo nx 10m³ water truck, welcome to get more information from our factory. For price consultation, contact us.
Customised New Truck For Sale
We have 20 Years Truck Manufacturing Experiences
Sprinkler Water Truck is also known as sprinkler, landscaping sprinkler, water tanker, water truck. Sprinkler is mainly used for all kinds of road washing, drinking water transportation, tree watering, landscaping sprinkler, road construction sprinkler, factory and mining enterprise construction water, fire fighting and so on. Sprinkler mainly consists of chassis, water tank, water pump, spraying system, control system and safety devices. At the same time can be used for temporary emergency fire sprinkler, each sprinkler is equipped with a special interface for fire fighting. The engine drives the gearbox, and the extractor installed on the gearbox drives the sprinkler pump, which generates the main power to spray the liquid inside the tank through the pipe network. Adopting automatic production line tank production process is divided into: material, automatic welding of splicing plate, rotational molding of the head, tank body once roll forming and other domestic advanced production process. Tank materials are mostly made of high-quality carbon steel plate. For special applications, 304 stainless steel can also be used according to customer needs. Tank volume is "4 CBM, 5 CBM, 6 CBM, 8 CBM, 10 CBM, 13 CBM, 15 CBM" and so on.
Key parts:
Front flush, level gauge, two water inlet (one for water filing from fire hydrant, the other for water pumping), ball valvel (control water flow direction), manhole, side spray, rear spray, water cannon (360 degree).
FEATURE 01
Road Cleaning
FEATURE 02
Greening Irrigation
FEATURE 03
Dust Reduction and Cooling
FEATURE 04
Fire-fighting Assistance
FEATURE 05
Emergency Water Supply
FEATURE 06
Applicable Mining Areas
For quick inquiry, please contact:
Hedy He Sales Manager
Whatsapp: +86 188 2740 1066
Email:hedy@clw-autos.com
|
Truck Specification |
||
|
Condition |
Brand New, Left / Right hand drive, 4x2 (6 wheels) |
|
|
Overall dimension |
8500x2500x3000 mm |
|
|
Weight |
GVW |
18000kg |
|
Curb Weight |
7460kg |
|
|
Chassis |
Brand |
Sinotruk |
| Wheelbase | 4300 mm | |
|
Steering Gear |
Power steering, hydraulic steering with power assistance |
|
|
Fuel box |
400liters |
|
|
Cab |
H77L cab |
|
|
Engine |
Fuel type |
Diesel |
|
Brand |
Weichai |
|
|
Model |
WP10.300E22 |
|
|
Horsepower(HP) |
300 |
|
|
Cylinder number |
In-line 6 cylinders,water cooling, four-stroke, super-charge and middle cooling,direct-injection |
|
|
Transmission |
Type |
Manual |
|
Model |
HW19710, 10 Forward and 2 Reverse Gear |
|
|
Axle |
Front/Rear |
VGD71 Front axle / MCX16ZG Rear axle |
|
Tire |
Quantity |
6 pcs with 1 spare tire |
|
Specifications |
12.00R20 |
|
|
Water Tanker |
Tanker volume |
1,000Liters / 12,000Liters |
|
Material |
Q235 carbon steel |
|
|
Thickness of Tanker |
6 mm |
|
|
Water Pump |
China famous brand self-suction water pump |
|
|
Standard equipment |
Front Flush,Rear Spray,Side Spray,Water Cannon |
|
|
Suction height of truck pump |
＞7 m |
|
| Full tank suction time | ＜15 minutes | |
| Sprinkling width of front/rear/side sprinkler | ≥ 14m | |
| Range of water cannon | ≥ 28 m | |
