Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of faw j6p 8x4 25 tons conjoint towing wrecker truck in China. If you're going to buy high quality faw j6p 8x4 25 tons conjoint towing wrecker truck, welcome to get more information from our factory. For price consultation, contact us.
There are several types of wrecker trucks from our fatory, with the most common types being:
Flatbed tow truck: A truck with a long flatbed at the rear that can be hydraulically lowered to ground level, allowing the vehicle to be winched or driven onto it for transport.
Hook and chain tow truck: A truck equipped with a hook and chain system that attaches to the vehicle's axle or frame for towing. This type is less commonly used today, as it can cause damage to the towed vehicle.
Wheel-lift tow truck: A truck with a metal yoke that slides under the vehicle's front or rear wheels and lifts them off the ground. This type of tow truck minimizes the risk of damage to the towed vehicle, as it only makes contact with the tires.
Integrated tow truck: A truck that combines elements of the wheel-lift and boom systems, allowing the vehicle to be lifted and towed simultaneously. This type is commonly used for heavy-duty towing and recovery operations.
Professional R&D team
Professional experts to design and customize as your project demands
Senior project managers effectively control all aspects of the project
Quick delivery
Our factroy Located in Suizhou city, It is the Capital of Special Purpose Vehicles. We have quick delivery time around 40-50 days(production time)
24 hours
Online Service
One Year
Warranty Time
365 days
Services
25-40 days
Quick Production time
What is a wrecker? A wrecker is a type of tow truck with a large boom and additional cable winch, which allows it to recover vehicles from various locations. For example, a wrecker may be used to flip a car or truck that has rolled over, pull a vehicle from a precarious position off the road, or separate multiple vehicles which have become squashed together.
Wreckers are typically used when recovery is needed rather than just a straightforward tow. They are also used when heavy-duty towing is required in order to tow big vehicles like a semi, trailers, buses, or any commercial vehicle.
Tow trucks may also have a boom and winch, but they are typically a simple flatbed setup that makes it quick and easy to pick up a vehicle. So, if you just need your car picked up, and it's not trapped off the road, or rolled over, then it's likely that a flatbed tow truck is what's going to show up to assist you.
Most tow companies operate a fleet of vehicles that are predominantly flatbed tow trucks because they're incredibly versatile. However, they often have a wrecker standing by for serious accidents or recoveries. Therefore, if you're calling for a tow truck, it's essential to give the dispatch officer as much information as possible. The more information you can give them, the better they'll be able to gauge what you need and get you the right vehicle sooner. The last thing you want is for the wrong type of vehicle to show up, only to have to wait while they get a bigger tow truck or wrecker dispatched to your location.
| FAW J6P Truck Chassis | |||
|
Specification |
|||
|
Truck Model |
FAW J6P, New Model |
||
|
Driving Type |
Left Hand Driving |
||
|
Dimension(Lx W xH)(mm) |
12000×2496×3450(mm) |
||
|
Cabin |
J6P Flat cab, With one sleeper bed, with air-conditioner |
||
|
Fuel tanker capacity(L) |
400L with locking fuel cap |
||
|
Clutch |
Single-plate dry clutch Φ430mm |
||
|
Engine Model |
Model |
CA6DM2-39E3F(,4- stroke direct injection diesel engine, 6 cylinders in line with water cooling , turbo-charging and inter-cooling |
|
|
Horse Power, |
390hp |
||
|
Engine Brand |
XICHAI Diesel |
||
|
Emission |
EURO II |
||
|
Power |
287KW |
||
|
Displacement: |
11L |
||
|
Fuel Type |
diesel |
||
|
Transmission |
Model |
CA10TAX190M, 10 forwards and 2 reverse |
|
|
Brake system |
Service brake |
Dual circuit compressed air brake |
|
|
Parking brake |
spring energy, compressed air operating on rear wheels |
||
|
Steering system |
Model |
ZF |
|
|
Front axle |
2*9500kgs. |
||
|
2*16000kgs Loading capacity |
|||
|
Chassis |
Frame: Double decker frame (8+5/300) Front suspension: semi-elliptic leaf springs, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension: semi –elliptic leaf spring and bogie springs |
||
|
Color |
Optional |
||
|
Tire |
12.00R20 All Steel Radial tire, 12+1 spare tire |
||
|
Electrical system |
Operating voltage |
24V,negative grounded |
|
|
Starter |
24V,7.35KW |
||
|
Alternator |
28V,1500W |
||
|
Batteries |
2*12V.165Ah |
||
|
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light. |
|||
| Under Wheel lifting capacity | 25Tons. 25 Tons, 25MT. | ||
| Winch | 2 nos, 10Tons, or 15Ton, or 20Tons for option | ||
| Boom | 25 Tons Extendable or fixed | ||
| Other equipment | a complet set of alarming lamps, forks, Remote control etc | ||
CLW Group, Chengli Special Automobile Co., Ltd is a manufacturer for special trucks and trailers, established in 2004. We have many successful cases for supporting towing services, Road recovery services, Emergency Rescue on the road for breakdown accident trucks, cars, buses etc. For more information, please contact: Ms. Helen Jiang
