Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of animal bulk feed delivery truck in China. If you're going to buy high quality animal bulk feed delivery truck, welcome to get more information from our factory. For price consultation, contact us.
The 30 CBM Bulk Feed Truck is engineered with advanced auger technology and strict manufacturing standards to ensure reliable performance and long service life.
Equipped with a high-efficiency auger system featuring graphite bearings and optimized clearance, pitch, and speed, the truck delivers smooth, maintenance-free operation while effectively reducing feed crushing.
The fully welded tank body ensures excellent sealing, preventing material loss and contamination. Automatic loading and unloading enable continuous operation, significantly improving working efficiency.
Specialized anti-corrosion coating provides strong resistance to frequent disinfection environments in livestock farms, ensuring long-lasting protection.
User-oriented designs include a sloped roof, anti-slip top walkway, stainless steel rear ladder, intelligent alarm system, and rear work light, enhancing safety and convenience during operation.
Each truck undergoes strict factory testing using professional inspection equipment to guarantee consistent quality and reliable performance.
30 CBM Large Capacity – Optimized design for efficient bulk feed transportation
Advanced Auger System – Graphite bearings for longer service life and maintenance-free operation
Low Feed Crushing Rate – Optimized auger clearance, pitch, and speed
Fully Welded Sealed Tank – Prevents leakage, reduces loss, and avoids contamination
Automatic Loading & Unloading – Continuous operation for higher working efficiency
Heavy-Duty Reinforced Structure – Fully welded beams and ribs for long-term durability
Anti-Corrosion Coating – Resistant to frequent disinfection in livestock farms
Safe & User-Friendly Design – Sloped roof, anti-slip walkway, stainless steel ladder
Intelligent Alarm System – Alerts the driver if the lifting auger is not reset
Rear Work Light – Convenient and safe operation at night
Strict Factory Inspection – Tested with professional inspection equipment before delivery
|
Truck Chassis |
|||
|
Condition |
New condition/Left hand drive/6x4 |
||
|
Chassis
|
Brand |
SHACMAN |
|
|
Gross Vehicle Weight (kg) |
25000 |
||
|
Loading Weight (kg) |
10870 |
||
|
Wheelbase(mm) |
4600+1350mm |
||
|
Dimensions(mm) |
9975×2495×3774(mm)mm |
||
|
Front Axle |
MAN 7.5T |
||
|
Rear Axle |
16T STR double reduction5.262 |
||
|
Wheel track (front/rear) (mm) |
2036/1850 |
||
|
Clutch |
Chinese made clutch |
||
|
Max. driving speed(km/h) |
80km/h |
||
|
Steering Gear |
Power steering, hydraulic steering with power assistance |
||
|
Tire |
12.00R20 10pcs with one spare tire |
||
|
Fuel box |
400L aluminum alloy |
||
|
Transmission |
manual operation, FAST 9JS135 9 forward and 1reverse |
||
|
Cab |
Medium-length flat roof Hydraulic suspension Air/Hydraulic main seat Electric automatic constant temperature AC |
||
|
Engine
|
Brand |
Weichai engine |
|
|
Model |
WP10.340E32 |
||
|
Fuel type |
Diesel |
||
|
Displacement(ml) |
9.726 L |
||
|
Power(kw) |
250kw |
||
|
Horsepower(HP) |
340HP |
||
|
Max. Torque(N.m) |
1350N.m |
||
|
Cylinder number |
6-cylinder inline, direct injection design. |
||
|
Emission standard |
Euro III |
||
|
Superstructure Specification |
|
|
Fonction |
Bulk Feed Transportation |
|
Feed tanker capacity |
30CBM |
|
Feed tanker material |
high quality carbon steel /Aluminum alloy material |
|
Hydraulic auger |
Use the patent of intermediate support structure, Graphite bearing: Lifting auger steering with wireless remote control. |
|
Thickness of the tank |
4mm |
|
Compartment |
3 compartment to storage different kinds of feed |
|
Discharge |
Electric or hydraulic discharging |
|
Others |
The whole vehicle had 3 auger driven by 3 units 5.5kw motors and 380V external power supply .the top auger are hydraulic controlled for lifting and can rotate 180 degree left and right . |
Screw conveyors are used to transport feed from the bottom of a silo to the discharge port. They can include bottom screws, vertical screws, and top screws, with the top screws capable of rotating left and right.
Height limiter: Detects the working height of the top screw; when it exceeds the preset safe height, the system automatically stops operating.
