ISUZU FTR 10Ton Flatbed Truck

Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of isuzu ftr 10ton flatbed truck in China. If you're going to buy high quality isuzu ftr 10ton flatbed truck, welcome to get more information from our factory. For price consultation, contact us.

ISUZU FTR 4X2 6 Wheels 10Tons Flatbed Truck

With Hydraulic Flipping Plate/8Ton Winch/Front Outrigger Lift

1. Powertrain & Performance

• Engine: 205HP Isuzu 4HK1-TCG61 turbocharged diesel engine (Euro VI-b compliant)
• Torque: 700Nm@1,500rpm low-speed high-torque output
• Transmission: 68-speed synchromesh manual gearbox with overdrive
• Gradeability: 30% max slope climbing capability

2. Chassis & Loading System

• Frame Structure: Reinforced ladder frame with 8mm thick high-tensile steel
• Suspension: Front 9-leaf parabolic springs + Rear 10+8 multi-leaf spring suspension
• Payload Capacity: 10-ton design with 12-ton GVW rating
• Deck Dimensions: 6,800×2,450mm (L×W) flatbed with stake pockets

3. Flatbed Configuration

• Deck Material: 5mm thick anti-slip steel plate with reinforced crossmembers
• Sideboards: Removable 600mm high steel side panels (3+1 configuration)
• Loading Features: Rear folding gate + stake pockets for securing cargo
• Ground Clearance: 280mm for off-road loading capability

4. Operational Advantages

• Maneuverability: 6.5m turning radius for urban operations
• Braking System: Dual-circuit air brakes + ABS + exhaust brake
• Fuel Efficiency: 19-22L/100km with ECO mode switch
• Service Interval: 20,000km maintenance cycles

Driver Cabin & Safety

• Ergonomics: Wide-body cab (2,080mm) with air suspension seat, tiltable steering column, and multi-function LCD display

• Braking: Dual-circuit air brakes with ABS + exhaust brake for downhill control

• Lighting: LED headlights with auto-leveling and fog lamp configuration

8-Ton Winch

• High-capacity towing capability, with a rated pulling force of 8 tons, suitable for heavy-load dragging or recovery operations.

• Electric or hydraulic drive, ensuring stable operation even in challenging conditions (e.g., mud, slopes).

• Equipped with high-strength steel cable or synthetic rope, offering wear and corrosion resistance.

Front Support Leg Lifting System

• Hydraulically operated front support legs stabilize the front section of the vehicle and allow height adjustment of the deck's front end.

• Independent operation, working in coordination with the tilting deck for optimal loading/unloading angles.

• Typically features a manual or electric hydraulic pump for convenient operation.

Single-Section Hydraulic Tilting Deck

• Integrated hydraulic tilting mechanism, using cylinders to lift the entire deck in a single motion.

• Tilting angle of up to 45° or more, with anti-slip grooves or corrugated plate design for enhanced traction.

• Hydraulic system integrated into the chassis, saving space and simplifying maintenance.

How To Cooperate With Us?

WhatsApp/Wechat Number

+86 188 2740 1066

E-mail

hedy@clw-autos.com

1. 8-Ton Winch

Features:

• High-capacity towing with a rated pulling force of 8 tons, suitable for heavy-load recovery or cargo handling.
• Electric or hydraulic drive for stable operation in harsh conditions (e.g., mud, slopes).
• Equipped with high-strength steel cable or synthetic rope for wear and corrosion resistance.

Advantages:

• Efficient Recovery: Enables autonomous loading of disabled vehicles or heavy cargo, reducing reliance on external equipment.
• Enhanced Safety: The high-tonnage design ensures smooth towing and prevents overload risks.
• Versatility: Applicable in logistics, construction rescue, and various other scenarios.

2. Front Support Leg Lifting Device

Features:

• Hydraulically operated front support legs adjust the tilt angle of the loading platform.
• Can be controlled independently or synchronized with the tilting deck for optimized loading.
• Manual or electric hydraulic pump options for convenient operation.

Advantages:

• Precise Loading/Unloading: Adjusts platform inclination for smooth movement of heavy machinery (e.g., construction equipment).
• Superior Stability: Distributes load during operations, preventing front-end lift and protecting chassis integrity.
• Wide Adaptability: Suitable for uneven terrain or confined workspaces.

3. Single-Section Hydraulic Tilting Deck

Features:

• Integrated hydraulic tilting mechanism with a single-section design, powered by robust cylinders.
• Tilting angle typically exceeds 45°, with anti-slip tread or corrugated surface for enhanced traction.
• Compact hydraulic system integrated into the chassis for easy maintenance.

Advantages:

• Rapid Loading/Unloading: One-touch hydraulic operation improves efficiency over manual alternatives.
• Durable Construction: Single-section design reduces failure rates and evenly distributes loads for 10-ton capacity.
• Space Efficiency: Eliminates multi-segment folding, simplifying structure and reducing weight.
