ISUZU KV100 4X2 6,000Liters Refueling Truck For Fuel Express

Products Description

🚛 Vehicle Overview

This is an ISUZU KV100 chassis-based 6000L small mobile refueling truck (oil transport vehicle), belonging to the Fuel Express brand. It is a dedicated oil tank truck for finished oil transportation and onboard refueling, commonly used for internal diesel/gasoline refueling at construction sites, factories, and fleet depots.

📌 Applications and Scenarios

Primary uses: Refueling construction machinery, internal refueling for logistics fleets, self-supply refueling on farms and mines, and small-scale fuel distribution.
Compliance reminder: This type of vehicle is classified as a dangerous chemical transport vehicle and requires a full set of hazardous materials vehicle plates, operating permits, and qualified drivers and escorts. Daily parking and operations must strictly follow safety management regulations for flammable and explosive oil products.

Products Parameters

ISUZU KV100 6CBM Fuel Tank Truck
Chassis Specification
Chassis Model	QL104
Driving Model	4x2
Dimension	8000 x 2400 x 3500 mm
Cab	Original ISUZU KV100 cabin With Air Conditioner Left Hand Drive
Wheelbase	3360mm
Gross vehicle Weight	4000 kg
Front Axle Loading Capacity	2500 kg
Rear Axle Loading Capacity	4800 kg
Axle Number	2
Tire	7.00R16
	6pcs with 1 spare tire
Engine	ISUZU diesel engine 4 cylinders in a line, Water cooled, turbocharged, after cooled, cold start.
	Model: 4KH1CN6LB
	Horse power: 120 HP
	Displacement: 2999ml
	Emission standard: Euro 6
Transmission	Model: ISUZU
	5 Forward & 1 Reverse
Fuel Tank Capacity	100L
Upper structure parameter
Fuel tank capacity	6m3/6,000liters
Tank material	Carbon steel/ Stainless carbon/ Aluminum alloy
Compartment No.	ONE
Fuel dispenser	2 sets, flow rate at 70L/min English operation panel Showing unit price/ filling volume/ total price
Oil pump	2 Nos of 2.5'' Oil pumps, driven by TPO Independent pump in and pump out for each compartment
Filling hose	1 inch and 15 meters 2 sets for diesel and petrol separately
Filling hose reel	2 Nos
Filling nozzle	2 Nos
Manhole cover	2 sets with breath valves
Bottom valve	2 sets of APL aluminum pneumatic bottom valves
Level gauge	Each tank top is equipped with an electronic level meter
Operation compartment	Located at rear of truck with aluminum alloy door
Control system	Power on/off Lighting Fuel pump on/off Fuel dispenser on/off Main valve on/off Fuel level digital display
Others	2 sets of 4kg extinguishers 1 set of static belt
Painting	Color and design as customer's requirement
Special design	Tank body is covered by carbon steel van

Products Description

Chassis Load Capacity

Built on the ISUZU KV100 light truck chassis, offering reliable power and lightweight design for strong mobility in urban areas and construction sites, with compliant load capacity suitable for a 6m³ volume.
Tank rated volume: 6000L (6m³), suitable for transporting flammable fuels such as gasoline and diesel.

Tank Body and Structure

The tank is made of explosion-proof and corrosion-resistant materials, with standard protective handrails, maintenance ladders, loading/unloading ports, and safety warning lights on the top.
The rear is equipped with an anti-collision bumper and tail light assembly, with reserved brand markings and maintenance access points.

Core Refueling and Metering System

Onboard explosion-proof refueling machine assembly: Includes an SPV-brand metering refueling host, automatic retractable hose reel, and refueling nozzle, supporting precise refueling by quantity or amount, with cumulative flow statistics.
High-precision helical rotor flow meter: Manufactured by Chongqing NaiDe Industrial, with a nominal diameter of 50mm and 0.5-level metering accuracy, allowing direct reading of instantaneous flow and cumulative refueling volume, suitable for custody transfer metering.
Oil inlet/outlet ports: Marked IN and OUT quick-connect couplings, equipped with manual ball valves and pneumatic emergency shut-off valves.

Safety and Explosion-Proof Design

The vehicle's electrical system features an EX-class explosion-proof control box, labeled "Danger: Live Parts, Do Not Open Under Power," designed for flammable and explosive hazardous environments.
Equipped with pneumatic emergency shut-off valve controls, vapor recovery, emergency cut-off, and static grounding as part of a full set of safety devices for hazardous materials vehicles.
A sealed toolbox is standard on the side for storing maintenance parts and tools.

Detailed Photos

Refueling Compartment

Contains an explosion-proof refueling machine and automatic retractable hose reel for onboard self-service fast refueling.

Piping and Valve Assembly

Includes main fuel inlet/return control, precision mechanical flow meter, and emergency shut-off valve to ensure safe and accurate loading and refueling.

Explosion-Proof Electrical Control Box

Entire vehicle's electrical system is explosion-proof to eliminate fire hazards caused by sparks.

Emergency Shut-Off Valve Control

Pneumatically controls the emergency cut-off at the tank bottom, automatically stopping fuel flow in the event of a rollover or accident to prevent leaks.
