Dongfeng Knuckle Boom Truck
1. Dongfeng truck with 5tons crane
2. Crane brand:CLW Brand, or XCMG Brand
Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of dongfeng knuckle boom truck in China. If you're going to buy high quality dongfeng knuckle boom truck, welcome to get more information from our factory. For price consultation, contact us.
Product Description
1. Dongfeng truck with 5tons crane
2. Crane brand:CLW Brand, or XCMG Brand
3. Engine:Yuchai 140hp or Cummins Engine
4. We can do it according to your orders
Product Specification
| ||||||
Total weight(Kg) | 11950 | Driving type | 4 x 2 | |||
Payload (Kg) | 4505 | Overall dimension (mm) | 7650×2500×3550 | |||
Curb weight(Kg) | 7250 | Box internal dimension(mm) | 4450×2294×550 | |||
cab seats (man) | 2 | Front/Rear Suspension(mm) | 1320/2130 | |||
Approach/departure angle (°) | 22/10 | Wheelbase(mm) | 4700 | |||
Number of axles | 2 | Max speed(Km/h) | 90 | |||
Axle load(Kg) | 3400/8550 | Tire specification | 8.25-20, 7 pieces | |||
Engine | 170hp | Transmission | Manual,6 forward&1 reverse direct drive transmission | |||
| ||||||
Crane weight(kg) | 2160 | Max lifting weight(kg) | 6300 | |||
Max. Lifting moment(T.M) | 15.7 | Recommended power(kw) | 20 | |||
Max. Oil Flow of Hydraulic System(L/min) | 40 | |||||
Max. Pressure of Hydraulic System(MPA) | 20 | |||||
Oil Tank Capacity(L) | 90 | |||||
Installation Space(mm) | 900 | |||||
Rotation Angle(°) | 360°all rotation | |||||
Working Radius(m) | Arm Extension(m)/Max. Lifted Load(kg) | |||||
4.02 | 6.37 | 8.72 | ||||
2.50 | 6300 | 3000 | 1900 | |||
3.00 | 3870 | 3000 | 1900 | |||
3.50 | 3650 | 2750 | 1900 | |||
4.00 | 2480 | 1880 | ||||
4.50 | 2180 | 1860 | ||||
5.00 | 1920 | 1840 | ||||
5.50 | 1770 | 1680 | ||||
6.00 | 1680 | 1520 | ||||
6.50 | 1400 | |||||
7.00 | 1350 | |||||
7.50 | 1290 | |||||
8.00 | 1250 | |||||
Reference Photos
Details of knuckle boom truck
Production Process
① Production of chassis;
② Strengthening and refitting of girder and cab;
③ Installing the boom crane;
④ Installing circuit and testing;
⑤ Painting and Customized LOGO design.
Our Advantage
① High quality materials and integrated welding process;
② Ensure stable and reliable vehicle performance through strict testing;
③ Easy operation and we will provide all English Operation Manual, Guiding Video and Maintenance Notice to our customer.
Working Situation
Customer Visiting
Overseas Exhibition and After-sales Service
Sales Service
1. One year quality warranty for key parts such as axles, engine, transmission;
2. All spare parts would be OEM and supplied at cost prices;
3. Overseas service center to ensure efficiency after-sales service;
4. Regular after-sales visit to collect information about the vehicle's working status and feedback from customers.
FAQ
1. Q: Are you manufacturer or trading company?
A: We are direct manufacturer and are the well-known Special Purpose Truck manufacturer in China, our factory is located in South Suburb ChengLi Automobile Industry Park, Suizhou City, Hubei Province, it is very close to Wuhan City.
2. Q:How many is your min Order Quantity
A: One unit or one sets;
3. Q: What is your payment term?
A: 30% deposit, 70% balance before shipment by TT or Irrevocable LC at sight;
4. Q: How long is the specified delivery date from the date of order?
A: Usually it is 7-30 days, specified delivery date will depend on the detailed request.
5. Q: Contact Information?
A: For any question or request, please contact with me freely according to the following information
