Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of isuzu fvz 15ton milk tank truck in China. If you're going to buy high quality isuzu fvz 15ton milk tank truck, welcome to get more information from our factory. For price consultation, contact us.

ISUZU FVZ 10 Wheels 6X4 15Ton Milk Tank Truck With Aluminum Alloy

product key technologies

ISUZU FVZ 6x4 chassis

Durable and Reliable Chassis

Features a high-strength steel frame for enhanced durability and load-bearing capacity.

Excellent Mobility and Stability

Utilizes multi-leaf spring suspension to ensure stability and reliability, even under heavy loads.

Proven Transmission and Axle

The rear axle ratio is optimized for heavy-duty and complex road conditions, delivering strong traction.

Aluminum Alloy Tank Body

Food-Grade Hygiene & Safety

The interior wall is mechanically or electrolytically polished to a mirror finish, preventing residue buildup and enabling thorough cleaning and sterilization.

Excellent Thermal Insulation

The tank features a layered structure with polyurethane foam filling for optimal heat retention.

Corrosion Resistance & Durability

Stainless steel effectively resists corrosion from milk lactic acid, cleaners, and disinfectants, ensuring a long service life.

Products Parameters

ISUZU FVZ 6X4 Milk Tanker Truck
Chassis Specification
Chassis Model	QL1250FNFZY
Driving Model	4x2
Dimension	9000 x 2500 x 3100 mm
Cab	Original FVZ cabin With air conditioner
Wheelbase	4350+1370 mm
Gross vehicle Weight	25000 kg
Curb Weight	7505 kg
Front Axle Loading Capacity	7000 kg
Rear Axle Loading Capacity	10000 kg X2
Axle Number	3
Tire	385/65R22.5 315/80R22.5
Tire	10pcs with 1 spare tire
Engine	ISUZU diesel engine 6 cylinders in a line, Water cooled, turbocharged, after cooled, cold start.
	Model: 6HK1-TCG60
	Horse power: 300 HP
	Displacement: 7790ml
	Emission standard: Euro 6
Transmission	Model: ISUZU
Transmission	9 Forward & 2 Reverse
Upper Parameters
Tank Body Size (LWH)	5700 X 2400 X 1600 mm
Loading Capacity	15m3
Tank Body Type	Elliptical horizontal type, with the vehicle and tank integrated
Compartment No.	3
Tank Material	SUS304-2B
Inner Tank Thickness	δ 3.0 mm
Outsourcing Thickness	δ 1.0 mm
Milk Outlet Diameter	∮ 51mm
Thermal Insulation Material	70 mm polyurethane spray +10mm rubber plastic insulation cotton
Thermal Insulation Properties	The polyurethane spray foam is adopted, and the insulation performance does not exceed 2 hours within 24 hours
Tank Head Thickness	3 mm
Cleaning Method	CIP automatic cleaning, each warehouse is equipped with cleaning balls to meet 360° cleaning requirements

Chassis Pictures

Features Of ISUZU FVZ Milk Tank Truck

Isuzu FVZ Chassis (4350+1370mm wheelbase, 300 HP):

1. Tank Type

Horizontal elliptical, monocoque structure. Three evenly divided compartments (customizable) with three food-grade stainless steel manholes.

2. Inner Shell

3.0mm SUS304-2B food-grade stainless steel. Fully automated CNC welding, polished seams, and one-piece elliptical rolling.

3. Internal Head

3.5mm stainless steel dished head, formed in one piece for impact resistance and durability.

4. Baffles / Anti-Surge Plates

3.5mm dished stainless steel plates, fully welded with polished edges and reinforced rinsing rings for smooth, crevice-free interiors.

5. Support Structure

Internal skeleton and reinforcing ribs welded to the inner shell for enhanced load-bearing capacity and structural integrity.

6. Insulation

70mm sprayed polyurethane foam + 10mm rubber sponge. Maintains temperature within 2–3°C over 24 hours.

7. Outer Cladding

1mm overlapping stainless steel panels, welded-free for easy replacement and a clean, paint-free appearance.

8. CIP System

Food-grade stainless steel spray balls (two per compartment) enable 360° no-dead-angle cleaning. Independently controlled valves.
