Australia ADR Tri Axle Door Side Tipper Trailer For Mining

Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of australia adr tri axle door side tipper trailer for mining in China. If you're going to buy high quality australia adr tri axle door side tipper trailer for mining, welcome to get more information from our factory. For price consultation, contact us.

1. Our Side Tipper Application:

We, CLW Group, can produce many different combination side tipping trailers which specialize in Australian market that will meet your transport needs. The majority of our side tipping trailers are used in the mining industry, hauling ore to crushing plants and stockpiles.

We also can produce the superlink side tipper ( A-Trailer & B-double Trailer) to meet your huge hauling capacity.

2. Features of our Door Side Tipper Trailer:

• Our trailers have a low centre of gravity to provide safe transportation.
• They are able to tip over walls
• Transport and unload large rocks and high impact materials
• Safety, giving the driver a perfect view of the load whilst unloading
• Stockpiling of material in windrows
• 50 Degree tipping angle
• Equal load distribution
• Increases loads per day

3. Main Parameters for our ADR Side Tipper Trailer

• Axles: BPW stud drum brake or K-Hitch brand 11.5 ton ADR type.
• Suspension: K-Hitch brand ADR Mechanical Type, Air Suspension is available.
• Body: 5mm NM450 Wearing Plate
• Sub-frame: Fabricated "I" beam
• Hydraulics: two set of Chinese famous Cylinder (left cylinder: 150mm; door cylinder 80mm)
• Door operation: Cable type
• King pin: JOST 50mm or 90mm bolt in
• Guards: Stretched rubber
• Aero dynamics: Fibre nose cone
• Coupling: Ringfeder 96 AUS
• Tipping angle: 45°
• Paint: 2-pack under and top coats
• Electrical: ADR LED lamps /7 pin plugs
• Capacity: "A" trailer 14.5m³ rear B-trailer 24m³

• Electric Control Tarp is optional.

Wanna to know more ADR Australia Semi Trailer?  Please contact us:

Ms. Helen Jiang.

 +86 135 5419 5719 (WhatsApp/Mob)

 helen@clw-autos.com



We have developed our own side door opening mechanism, which allows the door of the trailer to be fully opened before the body reaches a 5° tipping angle. Our side tipping trailers are exported overseas especially for Australia. They are used in the coal and phosphate mining, where they have improved productivity against the conventional end tippers.

We are constantly developing ways to evolve our side tipper trailer. We have a trailer that can move 100 tonnes of salt over very dusty conditions without contaminating the product. The trailer was designed with a special type of door seal and a hydraulic opening lid, which consists of a steel frame covered with a plastic tarp. The lid opens to a vertical position when loading. The trailer is coated inside and out with a two pack epoxy salt-resistant paint, which protects the salt from contamination from the metal of the body.

If you're looking for high-quality tipping trailers or Water Spray Trailer in Australia, we're the ones to visit. Our friendly staff will always be ready to help you.
