Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of iveco 4x4 mobile medical unit in China. If you're going to buy high quality iveco 4x4 mobile medical unit, welcome to get more information from our factory. For price consultation, contact us.
We Are 100% Straight Factory Manufacturer For Ambulance Since 2004
The IVECO mobile medical unit(MMU) ambulance is a versatile and widely used emergency medical vehicle, also called the Ambulance Bus, Medical van, Rescue vehicle, Field hospital vehicle, Mobile clinic, Emergency medical vehicle, Disaster response vehicle, Mobile treatment unit, Medical RV,or COVID-19 mobile unit, Mass casualty unit, mobile ICU( Intensive care unit), Combat ambulance and Tactical medical vehicle, etc.
Features:
Iveco 4×4 ambulance
SOFIM diesel engine
four-wheel-drive off-road chassis
BOSCH high-pressure common rail
Durability
Reinforced 180mm high-strength boron steel frame for superior torsional resistance and heavy payload capacity.Specialized off-road axles and European-engineered chassis ensure reliability in harsh environments.
Safety and Stability
Low center of gravity design enhances stability on uneven terrain. Rust-proof aluminum anti-torsion shelter protects medical equipment and personnel.
Medical Compartment
Spacious, modular interior optimized for emergency procedures and infection control.Built with lightweight, corrosion-resistant materials for long-term use in extreme conditions.
Cutting-Edge Technology
Electronically controlled gearbox for smooth handling. Integrated with China's leading medical vehicle modification systems for rapid response.
|
Technical Specification |
|
|
Model |
CLW5044XJHCDP |
|
Driving type |
4X4 |
|
Passengers |
7 people (including patients) |
|
Dimension |
5916*2100*2700mm |
|
Wheelbase |
3310mm |
|
Front/rear overhang |
993/1597mm |
|
Front/rear truck width |
1670/1670mm |
|
Approach/departure angle |
37/17° |
|
Gross weight |
3855kg |
|
Curb weight |
3400kg |
|
Front /rear axle loading |
1655/2200kg |
|
Rated power |
95kw/129hp |
|
Displacement |
2798ml |
|
Maximum torque |
300/1600-2800 N.m/r/min |
|
Speed limit |
90km/h |
|
Minimum stable speed |
2.5km/h |
|
Maximum gradeability |
50° |
|
Bauchfreiheit |
260mm |
|
Minimum turning diameter |
15m |
|
Ramp angle |
29° |
|
Trench width |
650mm |
|
Vertical obstacle height |
280mm |
|
Fording depth |
750mm |
|
Engine model |
SOFIM8140.43S6 |
|
Fuel type |
Diesel |
|
Emission standard |
National Ⅵ |
|
Transmission |
Manual, 5 forward gear |
|
Transfer case |
Time-sharing four-wheel drive, Borg-Warner 4706 chain drive |
|
Tires |
255/85R16 LT 8PR |
|
Device Specification |
||
|
Medical alert appearance |
Truck body structure |
Steel reinforced frame construction |
|
The swing door on the right side, double-opening tailgate structure at the rear end |
||
|
Appearance |
All white, Red Cross logo at sides and rear door, with colorful strips all round |
|
|
Medical bay glass with black privacy film |
||
|
Warning lamps |
I-shaped integrated LED alarm light assembly |
|
|
Siren horn power 100W, wire control controller |
||
|
Blue flash lights installed on both sides and at the rear |
||
|
Medical cabin rescue facilities
|
Rescue system |
High strength aluminum alloy automatic on-board stretcher, with adjustable PVC waterproof foam mattress |
|
Thickened oval leg tubes, assistant upper wheels |
||
|
High quality stainless steel stretcher platform |
||
|
1 set of aluminum alloy rail-type infusion stands, with 2 folding hooks |
||
|
Medical oxygen control system |
Two 10L steel oxygen cylinders, with nominal pressure of 15MPA |
|
|
Two oxygen terminals |
||
|
A ventilator interface and a wall oxygen inhaler |
||
|
Equipped with a humidifying bottle to provide moist oxygen |
||
|
Medical electrical system |
Lamps |
12V cabin lights *6 |
|
Infusion spotlights *2 |
||
|
Inverter |
1000W vehicle-mounted sine wave |
|
|
220V multifunctional socket *3 |
||
|
12V multifunctional socket *1 |
||
|
Sterilizing lamp |
Intelligent timed ultraviolet disinfection *1 |
|
|
Air circulation system |
Air conditioning /heating |
1 set of rear air conditioning and rear heater device, independent control of cooling and heating |
|
Ventilator |
1 set of DC12V multifunctional ventilation fan with suction and exhaust |
|
|
Medical cabinet interior |
Box body |
The box is made of aluminum wit torsion tension resistance |
|
External middle door adopts flat push door, 180°rear double opening door |
||
|
Electroplated medal parts and integrated structural frame doors and components |
||
|
Cabinet |
One set of new environmental protection materials made of long strip equipment cabinet |
|
|
One set of oxygen cylinder cabinet made of new environmentally friendly materials, which can accommodate 2*10L oxygen cylinders |
||
|
One set of sliding door cage cabinet made of new environmentally friendly materials |
||
|
One set of long seat cabinets, including seat cushion, bracket and two point seat-belts |
||
|
Decoration |
Medical leather flooring |
|
|
Auxiliary devices |
Walkie-talkie |
One hands-free microphone installed in the cockpit and one in the medical compartment |
|
Fire extinguisher |
1kg dry powder fire extinguisher |
|
|
Waste pail |
1 pedal-style dirt bucket with cover |
|
|
Safety handrail |
A long handrail installed on the top |
|
|
Emergency hammer |
One installed in the cabin |
|
|
Optional devices |
|
|
Negative pressure purification device |
0.15M2 maximum air flow rate; 0.8m/s filtration rate; 0.3 microns particle size, reaching more than 99.995%(standard 99.7%). The relative pressure in the cabin is -30Pa to -10Pa. |
|
Traffic assistance system |
Dashcam and reversing video |
|
Stretcher |
Scoop stretcher |
|
Stair stretcher |
Loading capacity: 160kg |
We also provide different brands of Mobile Medical Unit Ambulance, such as Ford, ISUZU, JAC,JMC, SINOTRUK, Foton, Shacman,etc for you.
