FAW JH6 Fuel Delivery Truck – 30,000L Steel Tank, Optional Compartments
We are 100% Straight Factory Manufacturer
We have 100% Quality Assurance
1. Product Description
The FAW JH6 Fuel Transport Truck (30,000L) is a high-performance tanker designed for the efficient and safe transport of diesel, petrol, or other liquid fuels. Built on the reliable FAW JH6 8×4 heavy-duty chassis, it features a robust 30,000-liter steel or aluminum tank, with optional single or multi-compartment configurations to accommodate different fuel types.
Equipped with a high-precision flow meter, optional PTO-driven or electric fuel pump, and heavy-duty hose reel, this tanker ensures fast, accurate, and clean fuel dispensing. Safety features include emergency shut-off valves, anti-static grounding, fire extinguishers, and optional ADR compliance for international standards.
Ideal for fuel distributors, logistics companies, mining operations, and fleet service providers, the FAW JH6 tanker combines powerful engine performance, large fuel capacity, and customizable design to meet the demands of regional and long-distance fuel delivery.
2. Key Highlights
Trusted performance with strong load capacity, suitable for long-haul fuel transport across varied terrains.
Single or multi-compartment tank options for transporting diesel, petrol, or aviation fuel with flexibility.
Constructed from carbon steel, stainless steel, or aluminum alloy – corrosion-resistant and durable.
Ensures high-efficiency fuel loading and unloading for bulk or direct-to-equipment refueling.
Digital or mechanical meter for accurate fuel dispensing and inventory tracking.
Retractable hose reel with manual or auto-rewind function for fast and clean operation.
Equipped with emergency shut-off valve, fire extinguisher box, anti-static chain, ladder, and walkway with guardrails.
Available with 2–4 compartments, manholes, discharge valves, and baffles to meet various delivery requirements.
Complies with dangerous goods transport standards for international and regional markets.
Ideal for use in Africa, Middle East, Southeast Asia, and Central Asia, with support for left-/right-hand drive.
3. Product Specifications
| 1.Technical Specifications--FAW Chassis | ||
| Chassis Model | CA3310P25K2L7T4YEA80 | |
| Driving Model | 8X 4 | |
| Cab |
1.Flat-Roof, Full-Floating Cab 2.Right hand driving 3.With air conditioner 4.Power steering assistance 5.Electric window 6.Central lock |
|
| Wheel Base | 1900+5600+1350 mm | |
| Axle Loading (front/rear) | 9000/18000 kg | |
| External Dimensions (L x W x H) | 12000×2500×3200mm | |
| Max. driving speed | 90-100 km/h | |
| Engine | Model | CA6DM2-42 |
| Type | Xichai diesel engine 6 cylinders in a line Turbocharged & Inter-cooled |
|
| Horse Power | 420 HP | |
| Max output power | 309 KW | |
| Emission standard | Euro 2 | |
| Displacement | 11000 ml | |
| Rated Speed | 1900 rpm | |
| Gearbox |
1.Manual type, 2.C12JSDQXL220TA, 3.12 forward gears & 2 reverse |
|
| Clutch | Reinforced diaphragm clutch | |
| Tire | 315/80R22.5 | |
| Others | Air break | |
| 2.Technical Specifications-- Fuel Tank | |||
| Fuel Tank | Capacity | 30,000 liters | |
| Tank material | Q235 | ||
| Thickness |
4 mm tank shell 5.5 mm of end plate 4 mm baffles |
||
| Compartment No. | 1 or customized | ||
| Fuel Dispenser |
1 sets of Censtar brand,flow rate at 70L/min, English operation panel Showing unit price/filling volume/total price |
||
| Oil Pump |
1 No of 2.5 inch Oil Pump Aluminum alloy material; Driven by PTO; |
||
| Filling reel hose |
1 nos 1 inch and 15 meters With fuel filling nozzle |
||
| Level gauge (Optional) |
Float ball type at side of fuel tanker (Optional) UQZ-2 |
||
| Manhole cover | φ500mm | ||
| Bottom Valve | Aluminum alloy Pneumatic Bottom Valves | ||
| Discharging valve (Optional) | 1 setφ100 API discharging valves (Optional) | ||
| Operation compartment | Located at side of truck and with lockable door | ||
| Others |
With pump inlet and pump outlet 2 Nos of 4KG extinguishers 1 No of discharge pipe 1 No of static belt Emergency shut off control at rear of truck Ladder at rear of truck |
||
| Painting | Color and design as customer's requirement | ||
4. Detailed Photos
Manhole
Pump inlet and outlet
Dispenser system
Showing unit price/filling volume/total price
