Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of carbon steel isuzu ftr 15k liters fuel tanker truck in China. If you're going to buy high quality carbon steel isuzu ftr 15k liters fuel tanker truck, welcome to get more information from our factory. For price consultation, contact us.
Fuel tanker truck(also called fuel truck,fuel tank truck,fuel delivery truck,oil truck,oil tanker truck,oil bowser,diesel transport truck,gasoline transport truck,petrol tanker,petro dispenser truck) is used to transport fuel,oil,diesel,gasoline,kerosene and so on.
1.
Purpose of ISUZU fuel tanker truck: It used for vehicles refueling and mobile transporting Fuel/Petrol/Diesel, etc.
2.
Optional for Refueling System of
ISUZU fuel tanker truck: Oil pump, Hose reel with filling gun/Oil dispenser machine
3.
Tank shape of
ISUZU fuel tanker truck: shape of tank body can be designed to square round, round,Heat insulation device such as heating pipes, insulation.
5.
Refueling machine of
ISUZU fuel tanker truck: the refueling machine we use are tax controled oiling machine with accurate figure of volume, sum of money,etc.
6.
Optional parts of
ISUZU fuel tanker truck: reading meter for outlet and inlet,self-discharge valve at rail or side of tank body, compartment quantity according to the demand.
Feature--Stable and reliable ISUZU truck chassis;--High quality carbon steel material;--Independent compartment for different types of fuel types;--Serveral baffles inside tank to improve safety performance;--High pressure gas leakage test to ensure tank safety;
-- The tank shape adopts advanced welding technology and arc butt welding technology of the head as well as the integral one forming technology, fast installation, convenient maintenance, beautiful appearance.
--The anti-corrosion coating on the surface of the tank adopts sand blasting, derusting treatment, spraying, cleaning and other advanced technologies.
-- choose high quality domestic or imported safety accessories, carburetor and pump for users to choose, complete supporting.
--strictly adopt scientific advanced construction technology to ensure the lowest shrinkage rate and the highest dimensional stability in the low temperature state.
Condition | Brand new/left hand drive /4X2 | ||
| Brand | ISUZU | |
Wheelbase(mm) | 4500 mm | ||
Dimensions(mm) | 8400X2500X3100 mm | ||
Front/Rear Axle loading(kg) | 6300/13000 kg | ||
Tire | Quantity | 6 pcs with one spare tire | |
Specifications | 10.00R20 | ||
| Manual type MLD, 6 Forwards and 1 reverse | ||
| It can accommodate three people with cabin width 2mm and with Air Conditioner | ||
| Brand | ISUZU | |
Model | 4HK1-TC50 | ||
Fuel type | |||
Displacement(ml) | 5190 ml | ||
Power(kw) | 151kw | ||
Horsepower(HP) | 205HP | ||
Cylinder number | 4 | ||
Emission standard | Euro V | ||
| |||
| Capacity(cbm/liters) | 15 cbm/15,000 liters | |
Tank material | Tank material:Q235 high tensile strength steel,optional for aluminum alloy or stainless steel | ||
Thickness(mm) | 5mm of tank and 6mm of end plate | ||
| 1,or as customized | ||
| ∮500mm 1 set with breather valve | ||
| 1 set of API Pneumatic Bottom Valves | ||
| 1 set ∮100 discharging valves | ||
| Pneumatic control at tank two sides | ||
| At rear of tank | ||
| Color and design as customer’s requirement | ||
