Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of japanese brand isuzu 5ton refrigerated van truck in China. If you're going to buy high quality japanese brand isuzu 5ton refrigerated van truck, welcome to get more information from our factory. For price consultation, contact us.
1. Purpose: It used for transporting frozen fish, meat, chicken, duck, fresh vegetable and vaccinum etc.
2. Main parts: Refrigerating unit and control system.
3. Features: International chassis brand and International refrigerating unit brand for optional.
| ||||
Overall Dimension | 6000×2500×3300(mm) | Gross Vehicle Weight | 11495(Kg) | |
Curb Weight | 3900(Kg) | Loading Weight | 6000(Kg) | |
| ||||
Chassis parameters | Chassis Brand | ISUZU | ||
Cabin | Single, Left Hand Driving, with A/C | |||
| Model | 4 Cylinders | ||
Power | 88KW/120HP | |||
Emission standard | EURO V | |||
Displacement | 2.999L | |||
Fuel type | Diesel | |||
Gearbox | 5 Forward & 1 Reverse Gear | |||
Front and Rear Axle load | 2.5T/4.8T | |||
Wheel base | 3800(mm) | |||
Overhang( Front/Rear) | 1130/1505(mm) | |||
Angle(Approach/departure) | 20/16(°) | |||
Brake System | Air brake | |||
Steering Gear | Power Assistant | |||
Tire | 6 Pieces with 1 Spare Tire | |||
Maximum speed | 105(km/h) | |||
| ||||
Van | Box size | 4100×2300×2100(mm) | ||
Material | Fiberglass | |||
Insulating Layer | 8cm Polyurethane Foam | |||
Brand | THERMOKING | |||
Truck refrigeration unit | Model | KV300 | ||
Applicable temperature (ºC) | -18~0 | |||
Remarks | Part Optional: Ventilation slot | |||
Hook | ||||
External power supply | ||||
Side door | ||||
