Sinotruk 16 Tons Flatbed Towing Truck with 12 Tons Straight Crane

Customized for Cameroon Market

We are 100% straight manufacturer for special vehicles in China since 2004

Product Descriptions

Flatbed towing represents one of the most prevalent methods for transporting vehicles. This technique enables towing companies to securely and efficiently transport a diverse range of vehicle sizes. For those needing to transport machinery, delicate equipment, or luxury automobiles, flatbed towing is an excellent option.

A review of most towing companies reveals that flatbed tow trucks constitute a significant portion of their fleet. The adaptability provided by flatbed tow trucks is essential for towing operators, making them a fundamental component of any towing fleet and among the most frequently utilized vehicles.

Benefits of Flatbed Towing:

1. Minimizes Vehicle Mileage – For car dealerships, flatbed towing prevents unnecessary mileage accumulation during transport.
2. Reduces Risk of Damage – Flatbed towing significantly lowers the likelihood of vehicle damage compared to traditional tow and hook methods, even for already damaged vehicles.

3. Enhances Efficiency – Flatbed towing streamlines the process, eliminating time-consuming tasks like dropping drive shafts and connecting chains, resulting in quicker transport to the destination.

For quick inquiry, contatc Juniper:

Whatsapp/Mobile: +86 139 2570 3918

Wechat: 139 2570 3918

Email:juniper@clw-autos.com

Technical Parameters

General Technical Parameters
Overall Dimension		12500x2550x3800mm (mm)
Gross Vehicle Weight		25000kg
Curb Weight		21890kg
Chassis Specification
Chassis Parameters	Chassis Brand		Sinotruk HOHAN
	Driving type		6x4
	Cabin		3 seats with one sleeper bed Left Hand Driving Air Conditioned
	Engine	Brand	Weichai
		Model	WP12.400E201
		Horse Power	400HP
		Emission Standard	EURO III
		Displacement	11.59L
		Fuel Type	Diesel
	Gearbox		Manual, HOWO 10 Forward & 2 Reverse Gear
	Front and Rear Axle Loading		9.5T/16T/16T
	Steering Gear		Power Assistant
	Tire		12.00R20, 10 pieces+1 spare tire
	Fuel tank		400L
Superstructure Specification
Flatbed	Dimensions(LxW)		8500x2550 (mm)
	Max. Loading Weight		16,000(kg)
	Platform Height from the Ground		1070(mm)
Winch	Quantity		1pc
	Winch Rating Pulling Capacity		15,000 (kg)
	Length of Steel Cable		50(m)
Hoisting Organ	Rating Under-Pulling Capacity		16,000 (kg)
Crane	Brand&Model		XCMG GSQS300-4, straight crane
	Max. lifting capacity		12,000kgs
	Max. lifting moment		330kN·m
Remarks	A set of police lights and loudspeakers, A set of fork support Two pairs of Y-shaped steel plate forks A set of tire holding device Double Side Hydraulic Operation Handle with Your Language One truck can Tow 2 Cars
