ISUZU 6000Liter CAFU Fuel Refueling Truck- Diesel & Gasoline Delivery Service
The CAFU (Car And Fuel Unit) fuel dispenser truck is an innovative mobile refueling solution designed to deliver fuel directly to customers' locations. Its engineering integrates safety, efficiency, and smart technology.
CAFU's dual-compartment design maximizes productivity, safety, and sustainability-critical for modern fuel logistics. Companies like CAFU (UAE) and Booster Fuels (USA) use such systems to cut costs by ~20% and boost service speed by 30%+ versus traditional trucks.
Mobile Fuel Storage & Dispensing System
Core Functions
1. On-Demand Fuel Delivery
Private Vehicles: Enables scheduled doorstep refueling for individual car owners, eliminating trips to gas stations.
Corporate Fleets: Services logistics companies, taxi fleets, and rental car operators with bulk fuel delivery to reduce downtime.
2. Emergency Fuel Supply
Supports critical operations (e.g., hospitals, emergency responders) during power outages or natural disasters.
Rescues stranded vehicles in remote areas or on highways.
3.Industrial & Off-Grid Solutions
Construction/Mining: Fuels heavy machinery and generators at remote job sites.
Agriculture: Delivers diesel/petrol directly to farms for tractors and equipment.
4.Event & Temporary Services
Powers generators at outdoor events (festivals, sports games, film sets).
Supplies fuel to temporary facilities like mobile clinics or military camps.
key Advantages
1.1 Simultaneous Multi-Fuel Delivery
CAFU Truck: Two compartments allow carrying two fuel types (e.g., gasoline + diesel), enabling dual-nozzle refueling for different vehicles at once.
1.2 Faster Turnaround Time
CAFU Truck: Two dispensers can refuel two vehicles simultaneously, cutting wait times for
CAFU Truck: Features dual emergency shutoff valves (one per compartment) and vapor recovery systems to prevent spills/cross-contamination.
2.1 Precision Metering & IoT Integration
CAFU Truck: Each dispenser has independent flow meters + IoT sensors, ensuring real-time tracking of fuel consumption per transaction.
2.2 Automated Safety Controls
CAFU Truck: Features dual emergency shutoff valves (one per compartment) and vapor recovery systems to prevent spills/cross-contamination.
The CAFU truck serves multiple sectors by eliminating the need for traditional gas stations:
On-Demand Fuel Delivery
Emergency Fuel Supply
Remote & Industrial Use
Event & Temporary Services
Data-Driven Optimization
| Overall Dimension | 6800 x 2400 x 2550 mm |
| Gross Vehicle Weight | 11000 kg |
| Curb weight | 5500 kg |
| Loading Weight | 6510 kg |
| Wheel Base | 3815mm |
| Front overhang | 1110mm |
| Rear overhang | 2022mm |
| Front wheel track | 1680mm |
| Rear wheel track | 1650mm |
| Cabin | 2 or 3 Passenger Allowed, with A/C, centrl locking, electric windows and multi-function steering wheel. |
| Engine | Diesel Engine
4HK1-TCG61
Watering Cooling, Four Stroke, 4 Cylinder in Line, Direct Injection |
| Horse Power/Emission | 190HP/Euro 6 |
| Gearbox | Manual, MLD,6 Forward & 1 Reverse Gear |
| Axle | 4000kg Front Axle, 7000kg Rear Axle |
| Max Driving Speed | 90 km/h |
| Tire | 235/75R17.5, 6 pieces with 1 spare tire |
| Tank Capacity | 6,000 Liters with 2 compartments |
| Tank Material | Q235 carbon steel, 5mm thickness Tank color and design can be customized |
| External box structure | Rear operation room equipped with aluminum alloy rolling shutter door and 2 pull straps |
| Manhole cover | 2 sets API manhole cover |
| Truck mounted dispenser | Dispenser with receipt printer, 2 sets mounted in the rear operation room |
| Oil Filling System | Bottom gravity discharge Oil Flow Meter,1 Unit Oil filling pump, 1 Unit Standard tool box 1 Unit |
API discharging port
Tamper Prevention - Smart electronic seals detect and log unauthorized access attempts to fuel compartments.
Regulatory Compliance - Meets API standards for secure fuel transfer operations
Two unit oil pump in & out
Tank-to-Ground Transfer: Safely unloads excess fuel from vehicle tanks to storage tanks using sealed, pressurized pumping.
Emergency Drainage: Quickly empties compartments during maintenance/leak scenarios.
Ground-to-Tank Refill: Pulls fuel from depot storage into truck tanks with metered precision.
Cross-Compartment Balancing: Adjusts fuel distribution between compartments during operations.
Operation control panel
You can easily do the operations by the control panel.
We can also take operation video to teach new user step by step.
Two units Censtar Fuel dispenser
Simultaneously refuels 2 vehicles (e.g., fleet trucks + passenger cars)
Cuts wait times by 50%+ compared to single-nozzle systems
Hubei CHENGLI Automobile Group is a large automobile manufacturing enterprise designated by the Ministry of Industry and Information Technology of China for producing various special vehicles.
The company is located in SUIZHOU City, HUBEI Province, and has employs over 7,000 people, including more than 500 technical personnel and over 1,800 skilled workers.
The company has an annual production capacity of 7,000 special vehicles.
Through professional vocation technical training, it annually provides society with over 500 automotive talents, making it a well-deserved incubator in the domestic special vehicle field.
