ISUZU 6x4 Flatbed Towing Truck with XCMG 8-Ton Crane

Products Description

Discover the powerful Isuzu QL1250FNFZY 6x4 wrecker truck integrated with an XCMG 8-ton straight arm crane. Perfect for heavy-duty recovery, versatile towing, and complex logistics.

The Isuzu 6x4 Wrecker Truck with Crane is engineered to set new standards in the recovery and towing industry. Combining the legendary reliability of an Isuzu heavy-duty chassis with the robust power of a dedicated XCMG 8-ton crane, this vehicle is a multi-functional powerhouse designed to handle the most demanding jobs with unparalleled ease and efficiency. It's not just a wrecker; it's a comprehensive recovery solution.

Key Features and Unmatched Adavantages

Ultimate Recovery & Towing Solution

Chassis & Powertrain

Model: QL1250FNFZY 6x4 Chassis
Engine: High-torque 6HK1-TCG60 diesel engine, 300 HP, compliant with Euro VI emission standards for global operation.
Transmission: Fastr 9-speed manual gearbox for smooth and precise control under load.
Advantage: Provides exceptional pulling power and reliability for heavy-duty recovery operations.

Driving & Suspension

Axles: Robust 7-ton front axle and 10-ton x2 rear axles for a massive load-bearing capacity.

Tires: 295/80R22.5 18PR high-load tires for excellent stability and grip.

Brakes: ABS and air brakes ensure maximum safety during towing and transit.

Cab & Operator Comfort

Cab: New Generation Isuzu VC61 5X-level cabin, designed for long-haul comfort.
Amenities: Air conditioning, power steering, central locking, power windows, multifunctional steering wheel, and a digital instrument cluster.
Advantage: Reduces operator fatigue, enhancing productivity and safety during long or complex jobs.

Wrecker & Crane Combo

Crane: Integrated XCMG 8-ton straight-arm crane.

Functionality: Enables self-loading/unloading of disabled vehicles and equipment without a second truck.

Versatility: The core advantage that makes this truck a cost-effective, all-in-one solution.

Products Specification

ISUZU Flatbed Towing Truck With 8Tons Straight Boom Crane
Chassis Specification
Chassis Model	QL1250FNFZY
Driving Model	6x4
Dimension	11000 x 2500 x 3900 mm
Cab	Right hand drive with air conditioner
Wheelbase	4650+1370 mm
Gross vehicle Weight	25000 kg
Curb Weight	15600 kg
Front Axle Loading Capacity	7000 kg
Rear Axle Loading Capacity	10000 x2 kg
Axle Number	3
Engine	ISUZU diesel engine 6 cylinders in a line, Water cooled, turbocharged, after cooled, cold start.
	Model: 6HK1-TCG60
	Horse power: 300 HP
	Emission standard: Euro 6
Transmission	Model: FAST
Transmission	9 Forwards & 2 Reverse
Tire	295/80R22.5 18 PR
Tire	10 pcs with 1 spare tire
Fuel Tank Capacity	400 L

Upper Parameters

Flatbed	Length	6,800mm
	Width	2,550mm
	Max. Loading weight	8,000kg
	Min. Angle of slope	15°
	Platform height from the ground	1,100mm
	Checker plate thickness	6mm (plate punching)
Winch	Quantity	1 piece
	Winch rating pulling capacity	8,000kg
	Length of steel cable	25m
Rear -arm hoisting organ	Rating under-pulling capacity	8,000kg
	Fully extended max under-hoisting capacity	2,500-4,800kg
	Max under-hoist useful length	1,340mm

Crane

Model

XCMG SQS200

Working Platform

360°turning (left or right), H-shape legs 360°

Extendable Boom Section

1 main boom + 4 extendable boom

Crane Type

Straight Boom Crane

Max. Lifting Capacity

Effectively: 8000 kg at 2.5 meters

Max. Working Radius

13.6 meters

Max. Lifting Height

15 meters

Max. Lifting Moment

200 kN.m

Max. Oil Flow of Hydraulic System

50+50 L/min

Max. Pressure of Hydraulic System

26 Mpa

Crane Weight

3709 kg

Landing Leg

4 Pcs hydraulic handing leg

Factory Real Shot Video For You

Dual-Functionality: Eliminates the need for two separate vehicles (a wrecker and a crane truck), saving on purchase cost, insurance, and maintenance.

Isuzu Reliability: Built on a globally trusted chassis known for its low operational costs and high resale value.

Operator-Focused Design: The comfortable and ergonomic cab ensures that operators can perform at their best, even during stressful recovery operations.

Global Compliance: With its Euro 6 engine and robust build quality, this truck is ready to meet the demands of international markets.

ISUZU Wrecker truck with 8-ton crane

Self-Sufficiency: Can recover vehicles that are not on the road (e.g., in a ditch, parked in a confined lot) by lifting them onto the bed.

Precision Control: Hydraulic controls allow for smooth and precise operation, ensuring safety during delicate recovery missions.

Multi-Purpose Use: Apart from towing, it can be used for light lifting tasks, loading/unloading machinery, or assisting in logistics, providing an additional revenue stream.

ISUZU Wrecker truck

Ideal Applications and operational scenarios

This versatile vacuum trailer is indispensable across numerous industries:

01/

The Isuzu 6x4 Wrecker with Crane is indispensable across numerous industries. Its primary application is in vehicle recovery, but its functionality extends much further.

02/

Highway Patrol & Emergency Services:

Perfect for quickly clearing overturned trucks or heavy-duty accidents from major highways, minimizing traffic disruption.

03/

Logistics & Transport Hubs:

Ideal for recovering broken-down trailers within ports, warehouses, and distribution centers. It can also reposition containers or equipment.

04/

Construction & Mining Sites:

Capable of recovering heavy machinery like excavators, loaders, and bulldozers from challenging terrain. The crane can also handle on-site material movement.

05/

Municipal Governments:

Used for clearing large abandoned vehicles, buses, or involved in disaster management and cleanup operations.

06/

Car Dealerships & Auction Houses:

An efficient solution for moving non-operational heavy vehicles like buses and large trucks without needing them to be driven.
