Philippines ISUZU GIGA 30Tons Refrigerated Truck

Drive Type: 8x4
Engine Power:350hp
Emission Standard: Euro 6
Van Capacity: 20 Ton/30 Ton
Refrigerator: Thermo King
With Hydraulic Folding Tail-plate

Product Details

Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of philippines isuzu giga 30tons refrigerated truck in China. If you're going to buy high quality philippines isuzu giga 30tons refrigerated truck, welcome to get more information from our factory. For price consultation, contact us.







ISUZU GIGA VC66 30 Tons 12 Gulong 8x4 Pinalamig Na Trak

May Hydraulic Folding Tail Plate



Products Description



The Philippines has high temperatures, high humidity, frequent typhoons, and complex road conditions throughout the year. This ISUZU 30-ton Refrigerated Truck is designed for the Philippine market. ISUZU GIGA chassis and equipped with ISUZU diesel engine and cold king independent unit. Therefore, the cooling performance and stability of this model are very high, and it has strong durability.



Use Advantages

ISUZU 6UZ1 / 6WG1 Engine





Suitable for long-distance heavy loads

The engine cooling system and refrigeration units are optimized for tropical climates.

Assemble Thermoking / Carrier Brands

Temperature -25℃ ~ +20℃

8x4 drive + high ground clearance, suitable for some unpaved roads in the Philippines.

Van box length around 10 meters

Isuzu diesel engine has a good reputation in the Southeast Asian market and is easy to maintain.

Isuzu has a well-established dealer network in the Philippines.

Reference Products Video







Products Parameters



ISUZU Refrigerator Truck

Chassis Specification

Chassis Model

QL131

Driving Model

8X4

Dimension

12000 x 2600 x 3990 mm

Cab

  • Original GIGA VC66 cabin
  • With air conditioner
  • Central locking
  • Power windows and doors
  • Multi-function LCD instruments

Wheelbase

1850+4575+1370 mm

Gross vehicle Weight

31000 kg

Front Axle Loading Capacity

75000 x 2 kg

Rear Axle Loading Capacity

13000 x 2 kg

Axle Number

4

Engine

  • ISUZU diesel engine
  • 6 cylinders in a line,
  • Water cooled, turbocharged, after cooled, cold start.

Model: 6UZ1

Horse power: 350 HP

Displacement: 9839 ml

Emission standard: Euro 6

Transmission

Model: ISUZU

8 Forward & 1 Reverse

Tire

295/80R22.5

12pcs with 1 spare tire

Fuel Tank Capacity

400 L

Refrigerated compartment body

Van Body Size (L*W*H)

9400 x 2440 x 2500 mm

Van Body Material

Extruded Polystyrene Sheet - XPS

Polyurethane - PU

Fiber Glass - FPR

Van Body Thickness

80mm / 100 mm

Refrigerator

Thermo King T-1080E

Temperature

-20 ~ 12 ℃

Optional Configuration

Ventilation Slot

Both Sides Fixing Slot

Top-hook / Rail

Hydraulic Tailgate - Carbon Steel / Aluminum Alloy



Products Pictures



Refrigerated trucks equipped with folding hydraulic taillifts (also known as hydraulic lifting taillifts or loading and unloading taillifts) can significantly improve loading and unloading efficiency, reduce labor costs, and ensure the temperature stability of goods transported in the cold chain.


The folding hydraulic tail plate is the "rigid configuration" for efficient loading and unloading of refrigerated trucks, especially suitable for cold chain transportation that is sensitive to aging and temperature. It is widely used in medicine, high-end food and other fields, and can significantly reduce the cargo damage rate and operating costs.


1. Mechanized loading and unloading

  • Instead of traditional manual handling, the goods are automatically lifted and lowered through the hydraulic system to realize the rapid loading and unloading of palletized goods or heavy goods.

2. Temperature control guarantee

  • Reduce the opening time and avoid temperature fluctuations in the refrigerated compartment (especially for sensitive goods such as frozen food and pharmaceuticals).

3. Adapt to a variety of scenarios

  • The foldable design saves space and is suitable for narrow spaces or scenarios where the tailgate needs to be opened and closed frequently.
5isuzu 8x4 refrigerated truck with folding tailplate
3isuzu 8x4 refrigerated truck
6isuzu refrigerator truck
7isuzu refrigerated van truck
4isuzu 12 wheels refrigerated truck

Batch Delivery

1Isuzu refrigerator truck
4howo redrigerated truck
2dongfeng refrigerator truck
1
6howo dump truck
5isuzu crane truck with straight boom crane
