Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of mercedes benz fire truck in China. If you're going to buy high quality mercedes benz fire truck, welcome to get more information from our factory. For price consultation, contact us.
We are 100% Straight Factory Manufacturer
We have 100% Quality Assurance
Foam Fire Truck, is a specialized vehicle designed to combat fires, particularly those involving flammable liquids, chemicals, or other situations where water alone is ineffective or could worsen the situation. These trucks are equipped with foam proportioning systems that mix water with foam concentrate to create a foam solution, which is then discharged through hoses or monitors to extinguish fires. It uses a fixed fire gun, which can control pitch and horizontal rotation at the same time. The fire extinguishing system is simple and convenient to operate and reliable to use. It has a novel appearance, scientific and reasonable layout, easy operation, and complete instrument display; it has complete accessories and tools, and adopts rotating, pulling and other structures, which are compactly arranged and easy to use, making it closer to the needs of fire fighting. It is a kind of heavy main battle fire truck with large loading capacity and multi-crew capacity. This product not only has Flammable Liquid Fires: Effective for fires involving gasoline, oil, jet fuel, and other hydrocarbons. Chemical Fires: Used for fires involving polar solvents like alcohols, acetone, and other chemicals. Industrial Fires: Ideal for refineries, airports, and manufacturing facilities where flammable liquids or gases are present. Wildland Fires: Foam can be used to create firebreaks or protect structures, espeicially airports firefighting, but also can be equipped with sets of elevated fire trucks and used jointly to meet the fire fighting in high-rise buildings.
Hedy He Sales Manager
Mobile: +86-188 2740 1066 (WhatsApp)
Email: hedy@clw-autos.com
Fire Extinguishing System
Large capacity
Efficient power system
Versatility
Security protection
Applicable scenarios
| Name | Mercedes Benz 8x4 PM180 Foam Fire Truck |
| Driving model | 8x4 |
| Dimension | 11710x2550x3560 mm |
| Cab |
|
| Gross vehicle weight | 37300 Kg |
| Fluid carrying capacity | 18100 Kg |
| Approach/Departure angle | 18° / 9° |
| Wheelbase | 1750+4600+1350 mm |
| Fuel tank | 390L/ steel material/ left side |
| Engine |
|
| Transmission | Automatic type, 16 forward and 4 reverse |
| Max.speed | 85 Km/h |
| Type | ESP Electronic vacuum pumps |
| Rated flow rate | 150L / s @1.0Mpa |
| Rated pressure | 1.0 Mpa |
| Diversion time | 7m Deep suction time≦100 s |
| Installation location | Rear-mounted |
| Rated flow rate | 120L / s@1.0Mpa |
| Main gun water range | 85 m |
| Foam range | 70 m |
| Pitch rotation | -45°~ +120° |
| Horizontal turning angle | 0~355° |
| Pump Room | Liquid Tank |
|
Rear - 4 suction ports |
Liquid tank capacity: 18000 Kg water tank capacity: 14000 Kg foam tank capacity: 4000 Kg |
|
Left / right sides - 3 spouts |
Tank material: 304 Stainless steel thickness: ≧3 mm |
| Left / right sides - 2 suction ports | Manhole diameter: ≧450 mm |
Electrical system
Carriage material
Equipment box structure
Roof structure
Sinotruk HOWO 4x2 Six Wheels Foam Fire Truck
Sinotruk HOWO 4x2 Six Wheels Fire Truck
ISUZU 4X2 Six Wheels Fireproofing Truck
If you have any needs or questions about products, feel free to ask me.
Situated in Suizhou city, Hubei province, central China, Hubei Chengli Special Automobile Co., Ltd, is among the major manufacturers authorized by the National Ministry of Industry and Information for producing 800 types of special purpose trucks. It is also recognized as the Export Center of Trucks and Spare Parts by the Hubei Province Government.
Collaborating with FAW, HOWO, FOTON, DONGFENG, JAC, JMC, SHACMAN, ISUZU, and others, we assure that all our products come with a one-year warranty and life time maintenance. Additionally, our service commitments are handled within 48 hours. CLW Group is dedicated to serving you and eagerly awaits your visit to our factory.
