Product Details

Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of isuzu 4x2 flatbed tow car carrier truck for 3 cars in China. If you're going to buy high quality isuzu 4x2 flatbed tow car carrier truck for 3 cars, welcome to get more information from our factory. For price consultation, contact us.

Products Description

ISUZU flatbed Tow Breakdown Car Carrier Truck Chassis:

ISUZU 700P Truck Chassis.
Wheel Base: 5200mm.
ISUZU engine, 190HP. EURO-5, or EURO-6.
Left Hand Drive.

ISUZU Rollback flatbed Tow Abandoned Car Carrier Truck Upper Equipment:

First flatbed floor: 7000*2400mm.
Second flatbed floor: 4600*2110mm.
Under-Lifting Arm: 3.5Tons.
Winch Capacity: 5Tons.
It can load two cars, and tow one car.

Envelope: helen@clw-autos.com

Address: Chengli Automobile Industry Park,Suizhou, Hubei, China

Whatsapp: +86 135 5419 5719

Wechat: +86 135 5419 5719

Parameters for ISUZU Rollback flatbed Tow Abandoned Car Carrier Wrecker Truck:

ISUZU General Technical Parameters
Overall Dimension			9200x2500x2950 (mm)
Gross Vehicle Weight			11695kg
Curb Weight			5695kg
Chassis Specification
Chassis Parameters	Chassis Brand		ISUZU 700P
	Cabin		3 persons, Left Hand Drive,Single Row and a half with a sleeper, with air conditioner
	Engine	Engine Brand	ISUZU brand
		Model	4HK1-TC51, 4 Cylinders
		Power	140KW/190HP
		Emission Standard	EURO V
		Displacement	5190ml
		Fuel Type	Diesel
	Gearbox		MLD, Manual, 6 Forward & 1 Reverse Gear
	Front and Rear Axle Load		4T/7T
	Wheel Base		5200(mm)
	Overhang( Front/Rear)		1110/2602(mm)
	Wheel track (front/rear) (mm)		1680/1650
	Angle(Approach/departure)		17/11(°)
	Brake System		Air Brake
	Steering Gear		Power Assistant
	Tire		235/75R17.5, 6 pieces+1 spare tire
	Maximum Speed		95(km/h)
	Fuel tank		125L
Superstructure
First Flatbed Platform	Dimensions		7000x2400 (mm)
	Max. Loading Weight		4000(kg)
	Operating Stroke		3700 (mm)
	Min. Angle of Slope		8(°)
	Platform Height from the Ground		1070(mm)
Second Flatbed Platform	Dimensions		4600x2110 (mm)
	Max. Loading Weight		2000(kg)
Winch	Quantity		1pc
	Winch Rating Pulling Capacity		5000 (kg)
	Length of Steel Cable		25 (m)
Underlift system	Rating Under-Pulling Capacity		3500 (kg)
	Fully Extended Max Under-Hoisting Capacity		1600 (kg)
	Max Under-Hoist Useful Length		1240 (mm)
Remarks	1. Equipped with One Set of Auxiliary Wheels 2. Bandages 4pcs 3. Yellow Warning Lamp 1pc 4. Double Side Hydraulic Operation
