Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of shacman m3000 8x4 truck mounted 25tons knuckle boom palfinger crane in China. If you're going to buy high quality shacman m3000 8x4 truck mounted 25tons knuckle boom palfinger crane, welcome to get more information from our factory. For price consultation, contact us.
--Truck mounted crane(also called Truck with Crane, Truck Crane) is used for lifting different kinds of cargo such as tree, steel pipeline, telegraph pole and stone etc.
--Truck mounted crane can be divided into various types as follows,
1) according to truck brands, there are SINOTRUK HOWO, FOTON, Dongfeng, SHACMAN, CAMC, JAC, JMC and ISUZU KTruck mounted crane;
2) according to driving model: 4x2, 4x4, 6X4, 6x6, 8x4, 8x8 and 10x4 Truck mounted crane;
3) according to lifting weight: 2tons 3.2tons 5tons 6.3tons 8tons 10tons 12tons 15tons 18tons 20tons 25tons 30tons KTruck mounted crane
4) According to crane type,there are telescopic and knuckle Truck mounted crane.
--Crane: We can supply International brand XCMG and PALFINGER for optional.
--Landing leg: Hydraulic control, top quality, easy for operation.
--Storage box: High quality carbon steel Q235
--Truck chassis: Militray quality shacman M3000 Diesel engine truck chassis
--Tire: 12R22.5 tubeless tire with high trafficability.
--Spk50002 is designed with high-strength steel plate and hexagonal boom, featuring high strength, light dead weight and strong lifting capacity.
--Effective lifting capacity: 16.5 tons, arm length: 16.8 meters.
--Arm frame form: folding arm
Parameters | |||
Drive Model | 8X4, Left hand drive | ||
Vehicle Main Dimensions | Dimensions(L x W x H)(mm) | 10500*2500*3850 mm | |
Wheelbase (mm) | 1800+4600+1350 mm | ||
Max. driving speed(km/h) | |||
Engine | Model | WP10.340E22 | |
Type | 6-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
Horse Power(HP) | 340HP | ||
Displacement (ml) | 9726 ml | ||
Emission standard | Euro II | ||
Brakes | Service brake: Dual circuit compressed air brake. Parking brake:(emergency brake): Spring energy, compressed air operating on rear wheels. Auxiliary brake: Engine exhaust valve brake. | ||
Cabin | M3000 cabin. It can accommodate three people, With Air conditioner | ||
Gearbox | 10 forwards & 2 reverses | ||
Steering Gear | ZF, Power steering, hydraulic steering with power assistance | ||
Fuel tank (L) | 400 | ||
Tire | 12R22.5 Tubeless tire , 12 + 1(spare tire) | ||
Flatbed | Loading Capacity(tons) | 30-40tons | |
Crane | Brand | PALFINGER | |
Working Platform | 400°turning(left or right), H-shape legs 360° | ||
Material | Q235 Carbon steel | ||
Boom Type | Folded type | ||
Max. Lifting Weight(kg) | Theoretical max.: 25000kg Effectively: 16500kg | ||
Max. Working Radius(m) | 16.8 m | ||
Max. Lifting height(m)(Hydraulic boom） | 20.5 m | ||
Max. Lifting height(m)(With mechanic boom）(Optional) | 27.2 m | ||
Max. Lifting Moment(T.M) | 49.0 T.M | ||
Max. Oil Flow of Hydraulic System(L/min) | 80-100L/min | ||
Max. Pressure of Hydraulic System(MPa) | 33.0 MPa | ||
Crane Weight(kg) | 5400kg | ||
