HOWO 12M 40FT Elevated Work Platform Truck

Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of howo 12m 40ft elevated work platform truck in China. If you're going to buy high quality howo 12m 40ft elevated work platform truck, welcome to get more information from our factory. For price consultation, contact us.





Sinotruk HOWO 12M 40FT Elevated Work Platform Truck



Factory Price For Sale



We are 100% Straight Factory Manufacturer in China with 100% Quality Assurance







• What is the Elevated Work Platform truck?



An elevated work platform truck, also known as an aerial work platform truck, aerial working truck, bucket truck, or cherry picker truck, among other names, is essentially a utility truck equipped with a hydraulic boom that features a man-carrying bucket at its end.



Elevated work platform trucks play a vital role across various industries such as municipal services, electric power maintenance, street light installation, advertising, communications, photography, landscaping, shipbuilding, transportation, operations at docks, airports, and ports, as well as in rescue and maintenance undertakings within large industrial and mining enterprises.



• Introduction of HOWO 12Meters/40Foot Elevated Work Platform Truck:



- Maximum operating height: up to 12 meters (40 foot)
- Load capacity of the platform: 200KG and above
- Platform rotation: 360°
- Advanced features: Imported electro-hydraulic proportional valve group with CAN bus control system, wireless remote control
- Operator interface: 5-inch LCD screen displaying real-time data such as detection arm length, elevation angle, platform height, and working height
- Working mechanism: Hexagonal working arm, synchronous telescopic, compact structure, high efficiency, large range
- Maintenance features: Built-in telescopic cylinder, double chain telescopic mechanism for easier fault observation and maintenance
- Boom structure: 4-section full chain type telescopic structure with built-in broken chain protector
- Leg design: Front V after H type legs, horizontal double-jointed legs telescopic, wide transverse span, "soft leg" protection function
- Coating: Vehicle electrostatic spraying for corrosion resistance and aesthetics



• What Elevated Work Platform Truck do we have?



1. Aerial platform height:14m,16m,18m,20m,21m,22m,24m,26m,28m,29m,30m, 32m, 34m, 45m, etc.

2. Chassis brand: ISUZU, FAW, FOTON, SINOTRUK, SHACMAN, DONGFENG,BEIBEN, JAC, JMC, KAMA, etc.



• For quick inquiry, please contact Ms.Juniper Gong:



 Whatsapp/Wechat: +86 139 2570 3918

 Email: juniper@clw-autos.com







Overall Dimension	5998×2050×2850mm
Gross Vehicle Weight	4295 kg
Wheel Base	2800mm
Cabin	LHD or RHD, Single row cabin,with A/C
Engine	Diesel engine,YN4100QBZL, 95HP, Euro 2
Gearbox	Manual, WLY6TS40, 6 Forward & 1 Reverse Gear
Axle	Front/Rear 2,000kg/3,500kg
Tire	7.00R16-14PR, 6 pieces with 1 spare tire
Max. working height	12m
Maximum operating range	6m
Platform operating range when maximum operating height	3m
Platform operating height when maximum operating range	8m
Landing leg	4 landing legs, front V rear H, independent operation
Leg span	Lateral leg span: 4700mm, Longitudinal leg span: 4560mm
Control system	Manual control and remote control
Bucket Loading Capacity	200kgs
