Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of 20cbm isuzu combination sewer cleaner in China. If you're going to buy high quality 20cbm isuzu combination sewer cleaner, welcome to get more information from our factory. For price consultation, contact us.
Designed to meet the demanding conditions of Russia's climate and infrastructure, the Isuzu 6x4 Sewer Cleaning and Vacuum Truck integrates high-power cleaning, deep suction capabilities, and cold-weather resilience into a single, efficient unit. Built on a reliable Isuzu rear double-bridge chassis with 6x4 drive, this truck ensures stability and performance in extreme environments. Its 20 m³ total tank capacity (6 m³ clean water tank + 14 m³ sewage tank, both constructed from 8mm thick carbon steel) provides ample storage for extended operations, while specialized anti-freeze features guarantee year-round functionality.
--Cold-Weather Optimized High-Pressure System
Equipped with a Pinfu high-pressure pump delivering 350 L/min flow rate and 180 bar pressure, ensuring powerful cleaning for urban sewer networks and industrial pipelines.
Integrated air-blow anti-freeze prevents water residue from freezing in pipelines during Russian winters, a critical advantage for uninterrupted operations
--High-Efficiency Vacuum Suction & Self-Cleaning Design
A dedicated Weifang 420 HP auxiliary engine powers a 6000 L/H Roots blower, enabling rapid suction of sludge, gravel, and viscous wastes with a suction depth of ≥8 meters.
--DN200 inlet/outlet pipes and a DN150 oblique suction port facilitate large-particle waste handling.
Hydraulic liftable tank with a rear-opening door + 600mm small access panel minimizes wear on main seals while simplifying maintenance.
--Operator-Friendly & Safety-Enhanced Configurations
Rear night working lights + arrow indicator lights improve visibility for safe night operations.
Hydraulic crane (includes 8-meter DN150 suction hose) with remote control for precise pipe positioning.
Transparent inspection window and pressure gauge for real-time monitoring.
--Durability for Long-Term Use
Sewage tank interior anti-corrosion treatment and polished surfaces extend lifespan.
Dual-purpose water-sewage interconnection and DN150 self-draining outlet enable flexible waste discharge.
|
Technical Specification |
|||||
|
Chassis Part |
|||||
|
Condition |
ISUZU, factory brand new 2025 |
||||
|
Wheelbase |
4350+1370 mm |
||||
|
Cab |
ISUZU cabin LHD, 1+2 seats Electric AC, Cooling Fan |
||||
|
Engine |
Engine brand |
ISUZU engine, 6KH1-TCG60 |
|||
|
Horsepower |
300hp |
||||
|
Fuel type |
Diesel |
||||
|
Emission standard |
Euro 6 |
||||
|
Transmission |
Manual type, FAST, 9 speeds forward and 2 reverse |
||||
|
Front axle loading |
7,000kg |
||||
|
Rear axle loading |
10,000kg |
||||
|
Tyre |
295/80R22.5 18PR, 10pcs with one spare |
||||
|
Upperstructure Configuration |
|||||
|
Tank dimensions |
Tank volume capacity |
20 m3, 20,000 litres |
|||
|
Clean water tank |
6m3, 6,000litres |
||||
|
Sewage tank |
14m3, 14,000litres |
||||
|
Jetting system |
High-pressure jetting pump model |
PINFL 350L/min |
|||
|
Vacuum system |
Vacuum pump model |
Roots Blower (6000 L/H) + Weifang 420 HP | |||
|
Horizontal suction range |
50 m |
||||
|
Drive system |
HP pump driven by Sandwich PTO |
||||
|
Filtration |
Dual-stage filtration protects pump from debris |
||||
|
Tank assembly |
Anti-overflow system |
Primary+ cyclone secondary valve |
|||
|
Dumping mechanism |
Front-mounted hydraulic lift |
||||
|
Accessories |
Top platform, filter ports, ladder |
||||
|
Reel |
Rear-mounted hydraulic reel, 160° hydraulic swing (deploy/ retract/ lateral positioning). |
||||
|
Discharge |
Side-mounted Ø100mm suction valve |
||||
|
Work platforms |
Both extended side platforms + toolboxs |
||||
|
Remarks |
Color is optional LOGO painting as per customer request |
||||
