Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of isuzu 16m3 compressed garbage truck in China. If you're going to buy high quality isuzu 16m3 compressed garbage truck, welcome to get more information from our factory. For price consultation, contact us.

ISUZU FTR 4x2 6 Wheels16m3 Compacotor Garbage Truck

Products Description

1. Reliable and Robust Chassis Performance

High-Efficiency Powertrain: Equipped with an Isuzu 4HK1 inline 4-cylinder diesel engine (5.2L displacement, 205 HP, 686 N·m torque), compliant with China VI emission standards, balancing power and eco-friendliness.
Exceptional Load-Bearing Capacity: A 5,000mm wheelbase ensures operational stability and ample space for body installation. Front axle capacity: 4.5 tons; rear axle: 9 tons, providing a solid foundation for waste compression.
Maneuverability and Accessibility: Air brakes with standard ABS ensure safety. Total vehicle length under 9 meters enables excellent turning radius for narrow streets.

2. Efficient and Intelligent Compression System

Large-Capacity Body: Box volume of 10-12 m³, constructed with high-strength wear-resistant steel and optimized internal structure for increased load capacity.
Advanced Compression Technology: Dual-cycle compression (horizontal pre-press + vertical compaction) with a compression ratio ≥ 1:3. Waste density reaches 0.6-0.8 t/m³, maximizing transport efficiency.
Low-Noise Hydraulic System: Load-sensing technology enables on-demand oil supply, reducing energy consumption and noise. Key components use international-brand valves for reliability and longevity.

3. User-Centric and Safety-Focused Design

Convenient Operation: Control panels installed in the cab and rear allow most operations without exiting the vehicle. Optional wireless remote control enhances safety and flexibility.

Multi-Layer Safety Protections:

Loader Safety: Dual seals between the hopper and body prevent leakage. Automatic alarm and mechanical support rods prevent accidental lowering.
Operational Safety: Interlock functions restrict compression if the vehicle is moving or the parking brake is disengaged.
Adaptive Loading Mechanism: Compatible with 120L/240L plastic bins, 300L metal bins, and small dumpers. Adjustable lifter hooks accommodate varying container heights.

Functions & Applications

Garbage Collection

Urban Residential Areas

Automatic Loading Garbage

Large-scale Factory

Compactor Garbage

Community

Garbage Transfer and Dumping

Mines

Compactor Garbage Truck Basic Structure

Garbage Truck Basic Constructure

Products Video

Products Parameters

ISUZU FTR 16m³ Compressed Garbage Truck
Chassis Model	QL518
Driving Model	4X2
Cab	Original ISUZU FTR cabin Left Hand Driving With air conditioner Central lock Steer Assistance Electric Window
Wheel Base	5800 mm
Axle Loading (front/rear)	6300 / 13000 kg
External Dimensions (L x W x H)	10560×2550×3280 mm
Net weight (Kg)	9870
Approach / Departure angle	20/12°
Max. driving speed	105 km/h
Engine	Model	4HK1-TCG60
	Type	ISUZU diesel engine, 4 cylinders in a line, Water cooled,turbocharged,after cooled , cold start.
	Horse Power	205Hp
	Emission standard	Euro 2
	Displacement	5193 ml
Gearbox	Manual type 6 forwards & 1 reverses
Clutch	Reinforced diaphragm clutch
Tire	295/80R22.5
	6 Pcs with 1 spare tire
Fuel box	120L /steel material
Garbage Truck Body(16m3)
Tanker body material	Quality high tensile Q345 carbon steel
Shape	rectangular box, arc-shaped rear
Thickness	Side 5mm, Bottom 6mm
Garbage Container Size	16 CBM
Filling hopper volume	1.5 CBM
Sewage box of filling hopper	500L
Working rotation speed	1400 r/min
Idle Speed	900 rpm
Compaction ratio	0.7-0.85T/m³
Compacting cycle time	≤35 s
Loading cycle time	≤15 s
Unloading cycle time	≤55 s
Oil pump displacement	63 ml/r
Hydraulic oil box size	120 L
System pressure	16 Mpa
PTO operation method	Pneumatic
Operation and Control	Both Automatic(Electrical) and Manual (hydraulic)
Others	With Pneumatic cover to avoid waste flying away during driving
Optional parts	Garbage Compactor whole body will be Electrophoresis treated for long time painting With remote control function

Products Photos

HOHAN NX Compressed Garbage Truck ☆With Swing Arm Mechanism

11sinotruk hohan 18m compactor garbage truck

Optional Configuration

Hanging Bucket Tipping Mechanism

Manual/Pneumatic Sealing Lid Mechanism

Triangle Bucket Rear Tipping Mechanism

Sealed Floor Bucket Rear Tipping Mechanism

Swing Arm Bucket Rear Tipping Mechanism

Swing Arm Mechanism
