FAW RHD 7m3 4X2 Compactor Garbage Truck

A refuse compactor truck is a specialized waste management vehicle designed to collect, compress, and transport municipal solid waste (MSW). Combining a heavy-duty chassis with hydraulic compaction technology, it significantly increases payload capacity while reducing collection frequency.

The FAW 7-Cubic Meter Compressed Garbage Truck, built on a robust FAW 4x2 chassis, is engineered for efficient, high-volume refuse collection and compaction. Featuring the FAW Tiger VH flat-top single cab in right-hand drive (RHD) configuration, it's ideally suited for markets requiring RHD vehicles. Powered by a reliable Yuchai 130 HP engine and equipped with a substantial Ø330 mm clutch, this truck delivers the necessary power and durability for rigorous waste management operations. Compliant with Euro II emissions standards, it features a strategic 3300mm wheelbase for excellent maneuverability in urban settings, paired with a Wangliyang 6-speed manual transmission for optimal control. The robust chassis supports a 2-ton front axle and a heavy-duty 7-ton rear axle, riding on sturdy 8.25R16 tires capable of handling rough access roads and landfill terrain.

Core Functions and Advantages



Core Functions



1. Collection: Crew members load refuse directly into the hopper at the rear of the truck.
2. Loading Cycle: The hydraulic-powered packing panel sweeps the waste from the hopper into the main body cavity.
3. Compression Cycle: A heavy-duty hydraulic compaction panel repeatedly compresses the waste within the main body, significantly increasing payload capacity and reducing volume (achieving the rated 7 cubic meter capacity after compression).
4. Transportation: The tightly compacted waste is securely contained within the sealed body during transport to the disposal site (landfill, transfer station, recycling center).
5. Ejection: Upon arrival, the hydraulic system activates the tailgate, and the compaction panel pushes the entire compressed load out efficiently for disposal.

key Advantages



1. Right-Hand Drive (RHD) Configuration: Essential for efficient and safe operation in countries with left-hand traffic systems (e.g.,Australia, India, South Africa, Thailand, Malaysia, etc.), allowing the driver optimal visibility during curb-side collection.
2. Robust Powertrain: The proven Yuchai 130 HP engine provides ample power for compaction cycles, climbing, and loaded travel. The large Ø330 mm clutch ensures smooth power transfer and enhanced durability under high-torque start-stop operations. The Wangliyang 6-speed transmission offers reliable gear selection for varying loads and terrain.
3. Optimized Chassis and Maneuverability: The 3300mm wheelbase strikes a perfect balance between stability with a full load and the agility needed for navigating narrow streets, alleys, and tight residential areas. 4x2 configuration keeps initial cost and maintenance efficient.



Urban Waste Management

High-density residential areas (narrow street access )

Apartment complexes with centralized bin stations

Commercial Sector Service

Shopping malls/food courts requiring daily collection

Office parks with limited loading zone space

Event and Public Space Cleaning

Temporary venues (festivals/sports events)

Municipal parks and pedestrian zones

Municipal Solid Waste Collection: Core fleet vehicle for city/town councils collecting household waste.

Commercial Waste Collection: Serving businesses, shopping centers, markets, and restaurants with high-volume waste streams.

Residential Community Management: Efficiently managing waste for large housing estates, apartment complexes, and gated communities.

Resort and Hospitality Waste: Handling waste from hotels, resorts, and tourist areas, especially where RHD is standard.

Event Waste Management: Effective cleanup during festivals, concerts, sporting events, and public gatherings.

Developing Markets: An excellent choice where reliability, proven technology (Euro II), right-hand drive, and cost-effectiveness are crucial factors.

Company profile



Hubei CHENGLI Automobile Group is a large automobile manufacturing enterprise designated by the Ministry of Industry and Information Technology of China for producing various special vehicles.
The company is located in SUIZHOU City, HUBEI Province, and has employs over 7,000 people, including more than 500 technical personnel and over 1,800 skilled workers.
The company has an annual production capacity of 7,000 special vehicles.
Through professional vocation technical training, it annually provides society with over 500 automotive talents, making it a well-deserved incubator in the domestic special vehicle field.
