Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of isuzu crane truck for sale manila in China. If you're going to buy high quality isuzu crane truck for sale manila, welcome to get more information from our factory. For price consultation, contact us.
ISUZU NPR NKR 700P 6 Wheels 5 Ton Truck Mounted Truck For Philippines Cebu Malina
The core competitiveness of Isuzu 700P truck-mounted crane in the Philippines lies in "one vehicle for multiple purposes", taking into account transportation and lifting, which is suitable for local fragmented logistics needs and infrastructure projects. Its durability and low operating costs are particularly suitable for small and medium-sized businesses.
Strong power and strong stability of the site
Efficient carrying capacity to meet the needs of medium-sized cargo transportation
The crane has flexible function and is suitable for a variety of loading and unloading scenarios
Adaptable and suitable for areas with poor road conditions in the Philippines
Good economy and long-term use cost
Reliability of the ISUZU brand

Chassis Key Technologies
Crane Key Technologies

|
ISUZU Crane Truck With 5Tons Straight Boom Crane |
|
|
Chassis Specification |
|
|
Chassis Model |
QL111 |
|
Driving Model |
4x2 |
|
Dimension |
7200 x 2400 x 3800 mm |
|
Cab |
|
|
Wheelbase |
3815 mm |
|
Gross vehicle Weight |
11000 kg |
|
Curb Weight |
6200 kg |
|
Front Axle Loading Capacity |
4000 kg |
|
Rear Axle Loading Capacity |
7000 kg |
|
Axle Number |
2 |
|
Tire |
235/75R17.5 |
|
6pcs with 1 spare tire |
|
|
Engine |
|
|
Model: 4HK1-TCG61 |
|
|
Horse power: 190 HP |
|
|
Displacement: 5193ml |
|
|
Emission standard: Euro 6 |
|
|
Transmission |
Model: ISUZU |
|
6 Forward & 1 Reverse |
|
|
Fuel Tank Capacity |
100L |
|
Upper Parameters |
|
|
Cargo Box |
|
|
Size (L*W*H) |
4600 X 2300 X 550 mm |
|
Loading Capacity |
8 Tons |
|
Bottom Thickness |
5 mm |
|
Side Thickness |
3 mm |
|
Material |
High quality Q235 carbon steel |
|
Crane |
|
|
Model |
XCMG - SQS125TL-5 |
|
Working Platform |
360°turning (left or right), H-shape legs 360° |
|
Extendable Boom Section |
1 main boom + 5 extendable boom |
|
Crane Type |
Straight Boom Crane |
|
Max. Lifting Capacity |
Effectively: 5000 kg at 2.5 meters |
|
Max. Working Radius |
15.7 meters |
|
Max. Lifting Height |
17 meters |
|
Max. Lifting Moment |
125 kN.m |
|
Max. Oil Flow of Hydraulic System |
63 L/min |
|
Max. Pressure of Hydraulic System |
22 Mpa |
|
Crane Weight |
2650 kg |
|
Landing Leg |
4 Pcs hydraulic handing leg |
|
Optional |
Hydraulic tipper box |
|
Box thickness as required |
|
|
Remote controller is optional |
|
|
Customized logo and color |
|








For quick inquiry, please contact Ms. Hedy He:
WhatsApp/ Wechat: +86 188 2740 1066
Email: hedy@clw-autos.com.




Hubei ChengLi Special Automobile Co., Ltd. is the core enterpriset Chengli Automobile Group and a large automobile manufacturing enterprise designated by the Ministry of Industry and Information Technology of China for producing various special vehicles. It is located in Suizhou City, Hubei Province, with production bases in the southern suburbs of Zengdu District and the Zengdu Economic and Technological Development Zone.
The company currently has total assets of early 10 billion yuan, covering an area of over 1,000 acres, and employs over 7,000 people, including more than 500 technical personnel and over 1,800 skilled workers. The company has an annual production capacity of 70,000 special vehicles it has signed industry-university-research cooperation agreements with universities such as Huazhong University of Science and Technology, Wuhan University of Technology, and Wuhan University of Science and Technology. Through professional vocational technical training, it annually provides society with over 500 automotive talents, making it a well-deserved incubator in the domestic special vehicle field.
We are 100% Straight Factory Manufacturer
We have 100% Quality Assurance
Welcome to visit our factory!
Hot Tags: isuzu crane truck for sale manila, China, manufacturers, suppliers, factory, price, Construction Truck
