Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of 90 ft mobile aerial work platform vehicle in China. If you're going to buy high quality 90 ft mobile aerial work platform vehicle, welcome to get more information from our factory. For price consultation, contact us.
ISUZU 27m 90 ft Mobile Aerial Work Platform Vehicle
Factory Price For Sale
We are Professional Special Vehicle Manufacturer in China Since 2004
An mobile aerial work platform vehicle, also known as aerial platform truck, aerial work platform truck, elevated work platform truck, aerial working truck, bucket truck, or cherry picker truck, among other names, is essentially a utility truck equipped with a hydraulic boom that features a man-carrying bucket at its end.
Elevated work platform trucks play a vital role across various industries such as municipal services, electric power maintenance, street light installation, advertising, communications, photography, landscaping, shipbuilding, transportation, operations at docks, airports, and ports, as well as in rescue and maintenance undertakings within large industrial and mining enterprises.
- Platform rotation: 360°
- Maximum operating height: up to 27 meters (90 feet)
- Load capacity of the platform: 200kg to 400kg
- Advanced features: Incorporates an electro-hydraulic proportional valve assembly with CAN bus control and wireless remote operation.
- Operator interface: Boasts a 5-inch LCD that provides real-time metrics, including detection arm length, elevation angle, platform, and working height.
- Working mechanism: Employs a hexagonal arm with synchronous telescopic action, compact design, high efficiency, and extensive reach.
- Maintenance features: Includes a built-in telescopic cylinder and a dual-chain mechanism for simplified fault diagnostics and upkeep.
- Boom structure: Comprises a 5-section full-chain telescopic design with an integrated broken chain safeguard.
- Leg design: Adopts front V after H legs, horizontally double-jointed telescopic legs with a broad transverse span and "soft leg" protection.
- Coating: Utilizes electrostatic vehicle spraying for enhanced corrosion resistance and visual appeal.
1. Platform type: Telescopic type, Folding type, Vertical lifting type (Scissor Lift)
2. Chassis brands available: ISUZU, FAW, FOTON, SINOTRUK HOWO, SHACMAN, DONGFENG, BEIBEN, JAC, JMC, KAMA, etc.
3. Aerial platform height options: 26 ft, 40 ft, 45 ft, 53 ft, 59 ft, 65 ft, 69 ft, 72 ft, 79 ft, 85 ft, 92 ft, 95 ft, 98 ft, 105 ft, 112 ft, 148 ft, etc.
WhatsApp:+86 139 2570 3918
WeChat: 139 2570 3918
Email: juniper@clw-autos.com
| Overall Dimension |
5998×2050X2850mm |
| G.V.M | 4495 kg |
| Wheelbase | 3360mm |
| Chassis brand | ISUZU |
| Cab | ISUZU 100P single row cabin, LHD, 2~3 Seats, with A/C |
| Engine | Diesel engine, ISUZU 4KH1CN6LB, 120HP, Euro VI |
| Transmission | Manual, ISUZU 5 forward and 1 reverse speed |
| Axle loading (Front/Rear) | 2500/4800kgs |
| Tyre |
7.00R16, 6 pieces with 1 spare tire |
|
Boom type |
Five section sexangular telescopic arm |
| Max. working height | 27 meters/90 ft |
| Working range at maximum working height |
5 meters |
| Maximum operating range |
11 meters
|
| Working height at maximum working range |
16 meters
|
|
Rotation Angle |
360° |
|
Outrigger |
4 landing legs, Front V Rear H design, Individually adjustment
|
| Leg span (Lateral/Longitudinal) |
4700mm/4560 mm |
| Control system | Manual control and Remote control |
| Bucket Loading Capacity | 200kgs~400kgs |
| Bucket Size |
1800X710X1200mm |
| Bucket Material | High strength aluminum alloy |
| Fence and platform | Stainless steel fence and Anti-slip platform |
| Color and logo | Customized with client's logo |
| Painting |
Electrostatic Spraying Treatment |
