Oil Field Use Fracturing Shacman F3000 Frac Sand Transport Dump Truck With Hydraulic Tipping

Shacman Frac Sand Transport Truck

Main Parameters

Product Name

Frac Sand Transport

Truck

Overall Size：

9650×2550×3480(mm)

GVW：

31000(Kg)

approach/departure angle：

28/20(°)

Loading Weight：

14400,14465(Kg)

Front/Rear Overhang：

1485/1790(mm)

Tare Weight：

16405(Kg)

Speed：

80(km/h)

Engine

Manufacturer

Displacement(ml)

Power(kw)

WP10.336E53

Weichai Power Co., Ltd.

9726

228

Emission

Standard：

GB17691-2005 EURO 5,GB3847-2005

Axle：

4

Front Wheel Track：

2011/201(mm)

Wheel Base：

1800+4375+1400,

Rear Wheel Track：

1800/1800,1860/1860(mm)

Tire Qty：

12

Tire Size：

12.00R20 18PR,12R22.5 18PR

Fuel Type

Diesel

Leaf Spring：

10/10/10,14/14/12

Axle Load：

6500/6500/9000/9000

Passenger：

3,2

Remark:

The vehicle is composed of a carriage, a lifting mechanism, a conveying mechanism, etc., and is mainly used to transport fracturing proppant in cooperation with oil field fracturing operations.

Optional without hydraulic support, optional box body, optional straight hydraulic device, an optional sand outlet at the rear, and optional cab of the same series with the chassis.

Optional rear view mirror and rear combination lamps. Side,

Material of the rear protective device: Q235B,

The side protection is connected by bolts,

Rear protection is connected by welding, the section size of the rear protection device (width × height) 60 × 100 (mm),

Height of the rear protection from the ground: 500mm.

Install a driving recorder with satellite positioning function.ABS system

Function

The fracturing sand tank truck produced by our company adopts domestic well-known heavy-duty dump truck chassis such as Beiben, Steyr, Howo, and Shaanxi Automobile. It is placed on the top, and the tail is equipped with a discharge port (various models can be selected according to user needs). The top of the box is designed with a circular feed port, anti-slip pedals, and guardrails. The top of the box can also be designed as a hydraulic roof according to user requirements.
