ISUZU FTR 6 Wheels 4x2 45meters Aerial Work Platform Truck

product key technologies

8isuzu ftr 4x2 aerial work platform truck

ISUZU FTR Chassis

Designed for heavy loads: The FTR's robust chassis structure provides an ideal foundation for installing a truck crane. Its frame offers high torsional rigidity, effectively distributing the immense pressure during lifting operations.
Strong load capacity: As a medium-duty truck, its carrying capacity aligns well with the lifting capability. It can handle lifting tasks while maintaining cargo transport function, achieving dual-purpose utility.

45Meters manlift

Telescopic Boom Design

Hydraulic cylinders enable synchronized or sequential section extension.

Flexible Operation Range

Lifting cylinders adjust boom angles for optimal positioning.

Precision Control System

Electro-hydraulic controls ensure smooth and accurate movement.

Comprehensive Safety Protection

Integrated safety systems include load moment and emergency descent.

9isuzu ftr 4x2 45m aerial work platform truck

Products Parameters

ISUZU FTR 45meters Aerial Work Platform Truck
Chassis Specification
Chassis Model	QL118
Driving Model	4x2
Dimension	9000 x 2400 x 3800 mm
Cab	Original ISUZU FTR Wide cabin With Air Conditioner Left Hand Drive
Wheelbase	4500mm
Gross vehicle Weight	18000 kg
Curb Weight	8200 kg
Front Axle Loading Capacity	6300 kg
Rear Axle Loading Capacity	13000 kg
Axle Number	2
Tire	295/80R22.5
Tire	6pcs with 1 spare tire
Engine	ISUZU diesel engine 4 cylinders in a line, Water cooled, turbocharged, after cooled, cold start.
	Model: 4HK1-TC60
	Horse power: 205 HP
	Displacement: 5193ml
	Emission standard: Euro 6
Transmission	Model: ISUZU
Transmission	6 Forward & 1 Reverse
Fuel Tank Capacity	200L

Upper Specifications
Working Platform	Size: 1600 x 700 x 1000 mm
	Material: Stainless Steel
	Rated Load: 200 kg
Boom Form	Synchronization telescope
Max. Working Height	45 meters
Outrigger Span	Landscape: 4200 mm
	Portrait: 4000 mm
	Front "V" type, Rear "H" type Independently adjustable (controlled)
Partition Boards & Walkway Boards	Material: Stainless Steel & Anti-slip
Rotator	360 ° of continuous rotation
Operation	Electrically controlled operation Manual emergency operation
Control System	CAN control system, equipped with wireless remote control, realize stepless speed regulation

Chassis Pictures

7isuzu 4x2 45m aerial work platform truck

5isuzu ftr 45m aerial work platform truck

Features Of ISUZU FTR Manlift Truck

ISUZU FTR Chassis

Mature Powertrain: Typically equipped with an Isuzu 4HK1-TC60 high-pressure common rail turbocharged diesel engine, with a displacement of 5.2L, delivering robust power and complying with China's National VI emission standards. It is paired with a technologically mature Isuzu manual transmission, ensuring efficient and reliable power delivery.

Professional Commercial Vehicle Chassis: The FTR is a heavy-duty truck chassis built with a high-strength steel double-layer frame (beam), providing a solid foundation for mounting the superstructure. The 4500 mm wheelbase is specifically designed as an ideal size for 45 meters manlift truck.

Excellent Driving Comfort and Safety: The cab is designed with a human-centric approach, offering a wide field of vision, excellent sealing, and low noise levels. Standard safety features include ABS and exhaust brakes, while some higher-end models are equipped with air brakes, parking brakes, power steering, and other features, ensuring easy and safe driving.

45 Meters Manlift

1. Great working height and range

Impressive working height: Reaches up to 45 meters, covering most construction and maintenance needs.
Strong horizontal reach: Over 20 meters of extension, allowing broad coverage without moving the base.

2. Strong obstacle-crossing ability

Compact chassis design: Enables passage through standard doorways and indoor use.
Excellent obstacle navigation: Multi-section arms can "reach over" obstacles for precise positioning.

3. Excellent stability and safety

Multi-level safety protection: Tilt protection, load sensing, emergency descent, and anti-misoperation systems.
Solid stabilization system: Four or more hydraulic outriggers with auto-leveling ensure extreme stability.

4. High load capacity and large platform

Spacious platform: Accommodates 2-3 workers with tools and over 200 kg capacity.
Flexible platform rotation: 180° or 360° continuous rotation for full-range coverage.

Application of Manlift Truck

High-rise Building Maintenance

For glass curtain wall cleaning, exterior painting, and facade repairs.

Municipal & Landscape Maintenance

Used for street light repair, tree trimming, and viaduct upkeep.

Industrial Equipment Servicing

Performs equipment installation and pipeline maintenance in plants.
