ISUZU GIGA 4X FTR 8Tons Straight Boom Crane Truck

We are 100% Straight Factory Manufacturer

We have 100% Quality Assurance

Products Description

Crane Truck is a set of lifting and transportation functions in one of the special vehicles, the full name of the "Car Lifting and Transporting Trucks". It is a kind of special truck which realizes the lifting, turning and lifting of goods through hydraulic lifting and telescopic system, and is usually assembled on the truck. The truck crane is generally composed of the chassis of the truck, cargo compartment, PTO(power take off) , crane and outrigger. With the ability of both cargo transportation and lifting operation, it is widely used in many fields such as logistics, construction, electric power maintenance, rescue and so on.

Products Operation Video

Key Feature

Versatility

Integrated lifting and transport functions
Reducing equippment and labor costs

Flexible and efficient

Rotatable and telescopic crane arm covers various working radii.

Structural Composition

Chassis part: adopts the chassis of cargo truck, with strong loading capacity.
Lifting mechanism: including hydraulic system, outrigger, boom (straight or folding boom), hook, etc., lifting capacity from a few tons to dozens of tons

Operation mode

Controlled by hydraulic system, support manual or remote control operation, some models are equipped with electronic limit and other safety devices.

Top Applications & Advantages

Logistics and transportation: loading and unloading of heavy goods (e.g. mechanical equipment, building materials).
Municipal engineering: installing street lights, billboards or carrying pipes.
Emergency Rescue: Rapid lifting of obstacles or accident vehicles.
Agriculture/Forestry: Moving agricultural machinery or timber.

Economy: one vehicle for two purposes, reducing equipment investment.
Convenience: suitable for decentralized or temporary operation.
Adaptability: it can be equipped with various attachments (such as grabs and clamps) to expand its functions.

Products Parameters

Chassis Specification
Chassis Model	QL1180JQFRCY
Driving Model	4x2
Dimension	9000 x 2500 x 3900 mm
Cab	Original FTR 4X cabin with air conditioner
Wheelbase	5000 mm
Gross vehicle Weight	18000 kg
Curb Weight	9650 kg
Front Axle Loading Capacity	6300 kg
Rear Axle Loading Capacity	13000 kg
Axle Number	2
Tire	295/80R22.5 18PR
Tire	6pcs with 1 spare tire
Engine	ISUZU diesel engine 4 cylinders in a line, Water cooled, turbocharged, after cooled, cold start.
	Model: 4HK1-TC60
	Horse power: 205 HP
	Displacement: 5200ml
	Emission standard: Euro 6
Transmission	Model: ISUZU
Transmission	6 Forwards & 1 Reverse
Upper Parameters
Cargo Box
*Size (LWH)*	5200 X 2300 X 550 mm
Loading Capacity	15 Tons
Bottom Thickness	5 mm
Side Thickness	3 mm
Material	High quality Q235 carbon steel
Crane
Model	XCMG - SQS200-4
Working Platform	360°turning (left or right), H-shape legs 360°
Extendable Boom Section	1 main boom + 5 extendable boom
Crane Type	Straight Boom Crane
Max. Lifting Capacity	Effectively: 8000 kg at 2.5 meters
Max. Working Radius	11.75 meters
Max. Lifting Height	15 meters
Max. Lifting Moment	200 T.m
Max. Oil Flow of Hydraulic System	63 L/min
Max. Pressure of Hydraulic System	26 Mpa
Crane Weight	3520 kg
Landing Leg	4 Pcs hydraulic handing leg
Optional	Hydraulic tipper box
	Box thickness as required
	Remote controller is optional
	Customized logo and color

Products Photos

High-quality Chassis

ISUZU 205hp diesel engine
6 Forwards Transmission
295/80R22.5 Tire

Practical Cargo Compartment

Economical and durable, strong transportation power
Exclusive use of lightweight design to improve the vehicle's greater carrying capacity, more fuel-efficient and improve transport capacity, higher annual payback rate.

Comfortable Drive

ISUZU Giga FTR VC61 4X Cabin
With air conditioner
Motorized windows and doors
Multifunction steering wheel

Straight Boom Crane

Straight arm for easier control of vertical take-offs and landings
Wider working radius
Relatively simple operation
Easy chassis mounting

Crane Rated Lifting Load
