Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of shacman 15m3 synchronous chip sealer in China. If you're going to buy high quality shacman 15m3 synchronous chip sealer, welcome to get more information from our factory. For price consultation, contact us.
Shacman L3000 Synchronous Chip Sealing Truck
Synchronous Chip Sealing Truck-also known as synchronous chip sealer, synchronous bitumen and aggregate sealer, binder spreader, synchronous sealer truck, or bitumen chip sealer truck-is a specialized vehicle designed for the application of synchronous chip sealing technology.
Perfect for both roadway development and preventative surface treatments.
| Chassis Model | SHACMAN L3000 4x2 240HP | ||||
| Overall Dimensions | mm | 8750*2500*3350 mm | |||
| Wheelbase | 5000 mm | ||||
| Tank Capacity | m3 | Asphalt Tank 8m3 | |||
| Gravel Tank 7m3 | |||||
| Curb Weight | kg | 10,800 kg | |||
| Gross Vehicle Weight (GVW) | 18,000 kg | ||||
| Engine | Power | 176 kW / 240 HP | |||
| Displacement | 5,130 mL | ||||
| Max Torque | 900 N.m | ||||
| Max speed | km/h | 90 km/h | |||
| Tire specification | 295/80R22.5 | ||||
| Electric System | 24 V | ||||
| Steering Position | LHD / RHD | ||||
| Transmission | 8 Speed Manual | ||||
| Color | Customized | ||||
| Equipment | |||||
| Tank Material | Carbon Steel | ||||
| Insulation Thickness | 50 mm Rock Wool Insulation | ||||
| Exterior Stainless Steel | 1 mm thick stainless steel plate | ||||
| Bitumen Pump | QGB950, Flow Rate: 950 L/min | ||||
| Proportional Valve |
CL-BLTS120.00 |
||||
| Control System | PLC Control | ||||
| Asphalt Nozzles | 28 pcs | ||||
|
Aggregate Gate |
14 way | ||||
| Burner | 2 × Riello G20 (Italy), 200,000 kcal/h each | ||||
|
Thermal Oil Pump |
RY40-25-160, from a well-known Chinese brand |
||||
| Spray Width | 4.0 m | ||||
|
Nozzle Spacing |
125 mm | ||||
|
Asphalt Spraying Rate |
0.25 to 3 L/m2 | ||||
|
Chip Spraying Rate |
2 to 22 L/m2 | ||||
| Asphalt Heating Speed | 20 °C/h | ||||
| Spraying Medium | Hot & emulsified asphalt (including SBS and rubber-modified types) | ||||
| Optimum Construction Speed | 3-6 km/h | ||||
| Speed Sensor |
Sodron SNG12 |
||||
| Temperature Controller | Pt100, from a well-known Chinese brand | ||||
