FAW JK6 20m3 Refuse Compactor Truck

Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of faw jk6 20m3 refuse compactor truck in China. If you're going to buy high quality faw jk6 20m3 refuse compactor truck, welcome to get more information from our factory. For price consultation, contact us.





FAW JK6 20m3 Refuse Compactor Truck



Refuse compactor truck also known as garbage compactor truck, compression garbage truck, refuse comression truck, waste compactor truck, waste disposal truck, refuse collection truck,is widely used for domestic waste, solid waste, plastic bottles and recyling objects and transport to waste treatment facilities. Garbage truck are mostly used by municipal facilities and private companies for waste management purpose. CLW factory has more than 20 years experience in producing garbage trucks, we have been sold more than 300,000 units in China market, and for more then 5,000 Units for oversea market.



Garbage compactor truck feature:

The compressed garbage truck consists of a sealed garbage bin, a hydraulic system, and an operating system.

* The garbage tank is made by high intense Q235b carbon steel, 6mm thickness

* Compression cycle time: 25-30s

* compression density: 0.6-0.8t/m3.

* unloading garbage is: 40s

* PLC control system: left & right control panel at rear part of truck, operation hanle at side of the truck, control panel at driver cabin

* Rear loading : lifting mechanism working with 120L/240/600L plastic garbage, can be customized as per customer's request



Maintenance tips:

1. Change hydraulic oil every six months
2. Clean sewage tank regularly
3. Grease the grease fitting and the slide inside the garbage bin can every week.
4. Cean the sticky garbage and debris on the hydraulic cylinder to avoid the dust ring or oil seal of the oil cylinder is damaged.

5. Clean the engine fuel filter, air filter, and engine oil Filters, hydraulic system air filters regularly.







FAW 20cbm Garbage Compactor Truck
Condition	New condition/Left hand drive/6x4
Chassis	Brand		FAW JK6
	Curb weight(kg)		1620kg
	Wheelbase(mm)		4350+1300mm
	Dimensions(mm)		10510*2550*3990 mm
	Axle Load(kg)		5000/11500/11500 kg
	Max. driving speed(km/h)		90 km/h
	Clutch		Reinforced diaphragm clutch
	Brakes		air brake
	Steering Gear		Power assistant
	Tire	Number	10pcs with one spare tire
		Specifications	12.00R22.5
Transmission	Manual type, 8 Forwards and 2 Reverses
Cabin	It can accommodate three people, With Air conditioner
Engine	Brand		Xichai
	Model		CA6DLD-26E5
	Horsepower/(HP)		260 HP
	Emission standard		Euro V
Upper Body
Item No.	Parameters
Volume Capacity(Garbage)	20.0 CBM
Thickness of the tank	6mm for the bottom and 5mm for the side carbon steel
Sewage tanker(one side of the truck)	200 L
Tail gate volume(L)	700L(Filling structure)
	Rated Pressure of Hydraulic system: 16 Mpa
	Filling time of loading system: 8-10 s
Specification	Working cycle of Loading system: 50-60 s
	Working cycle of the unloading system: 30-40 s
	Compress ratio:0.6:0.7
	Equipped with hermetic dustbin, hydraulic system and operating system.
	Automatic compress and uninstall, sewage can be collected by the sewage tank.
Equipment	Control system: China top brand operate system.
Painting and Logo	As customer's requirement
Other detail	China Famous brand and quality hydraulic pump, Multiple way valve, Tilt plate oil cylinder,
	Tail gate cylinder, Scraper cylinder, Slide plate cylinder, Push plate cylinder.







Contact Alice for quick inquiry  +86 180 7154 2196(whats app)





You can also choose different loading method for the garbage compactor truck
