ISUZU 6X4 16Tons Recovery Truck With 5Tons Crane For Costa Rica
We are 100% Straight Factory Manufacturer
We have 100% Quality Assurance
Flatbed clearance truck (Recovery Truck with Crane, Flatebed Truck with Crane) with crane because it is installed on the basis of flatbed clearance truck crane, generally installed for the XCMG crane, as the name suggests this can be called flatbed with crane clearance truck, with crane clearance truck, because of its characteristics not only can be towed by two clearance trucks, but also can be lifted to the faulty vehicle, also known as multifunctional clearance truck, this model is a type of clearance truck. And this model of the recovery truck is designed for Mexico, Costa Rica and so on country.
|
Chassis Specification |
|
|
Condition |
Brand New |
|
Chassis model |
QL1252 |
|
Driving model |
6X4 |
|
Dimension |
12200×2500×3950 mm |
|
Cab |
|
|
Overall Weight |
25000 kg |
|
Net Weight |
21550 kg |
|
Wheelbase |
5800+1370 mm |
|
Axle No. |
3 |
|
Front Axle Loading Capacity |
7,000 kg |
|
Rear Axle Loading Capacity |
10,000X2 kg |
|
Engine |
|
|
Model: 6HK1 |
|
|
Horse power: 300 HP, 221 KW |
|
|
Displacement: 7790 ml |
|
|
Emission standard: Euro Ⅵ |
|
|
Transmission |
Manual type, 9 Forward & 1 Reverse |
|
Tire |
295/80R22.5 18PR |
|
10 wheels with 1 spare tire |
|
|
Fuel Tank Capacity |
400L |
|
Upper Parameters |
|
|
Under Lift Boom |
Max. Under Lift Capacity: 16000 kg |
|
Max. Under Lift Capacity at Full Extension: 6500 kg |
|
|
Under Lift Boom Effective Length: 1700 mm |
|
|
Under Lift Telescopic Stroke: 1360 mm |
|
|
Ground Clearance when Under Lift Fully Retracted: 800 mm |
|
|
Flatbed |
Ground Clearance: 1200 mm |
|
Flatbed Plate Size(length*width): 8500x2550 mm |
|
|
Min. Tilt Angle: 8° |
|
|
Moving Range: 3760 mm |
|
|
Max. Loading Capacity: 16000 kg |
|
|
Winch |
Number: 1 |
|
Rated Towing Capacity: 80~150KN for option |
|
|
Diameter of Steel Rope: Φ16~Φ22 for option |
|
|
Length of Steel Rope: 50m |
|
|
Min. Line Speed: 4.52m/min |
|
|
Crane Parameters |
|
|
Brand |
XCMG SQZ105 |
|
Max. Capacity |
16,000 kg |
|
Lifting Height |
16.5 meters |
|
Working Radius |
14.5 meters |
|
Max. Lifting Moment |
300 KN.m |
|
Recommend Power |
45 kw |
|
Max. Pressure of Hydraulic System |
26 Mpa |
|
Oil Tank Capacity |
270L |
|
Rotation Angle |
360° All rotation |
