ISUZU Recovery Truck With 10Ton Crane
Drive Type:6x4
Engine: 460hp
Flatbed Length:8m
Flatbed Width:2.5m
Flatbed Loading Capacity:15~20Tons
Crane Loading Capacity:10Tons
With Hydraulic Ladder
One Tow Two
Hubei Chengli Special Automobile Co., Ltd is one of the leading manufacturers and suppliers of isuzu recovery truck with 10ton crane in China. If you're going to buy high quality isuzu recovery truck with 10ton crane, welcome to get more information from our factory. For price consultation, contact us.
ISUZU GIGA 6x4 15Tons Flatbed Tow Truck With XCMG 10Ton Folding Boom Crane
Products Description
- The Isuzu GIGA 6x4 recovery towing truck features a 5,200+1370mm wheelbase, ensuring superior stability and handling performance. This wheelbase configuration enhances the vehicle's ability to navigate challenging road conditions while maintaining excellent maneuverability.
- For propulsion, the truck is equipped with the Isuzu 6WG1 engine-a high-performance, highly reliable diesel engine delivering a maximum output of 460 HP. Paired with a 12-speed manual transmission, it ensures smooth power delivery and responsive gear shifting, making it well-suited for demanding operational environments.
- The recovery truck's design features a manually adjustable width as its key highlight. The base dimensions of the platform measure 8,000 mm in length and 2,500 mm in standard width, yet its advanced telescoping mechanism significantly enhances loading flexibility and cargo adaptability.
- The spacious platform accommodates various oversized loads, such as machinery, construction materials, and more. To facilitate efficient loading/unloading and cargo securing, the flatbed is equipped with a 15-ton winch, enabling effortless towing and load stabilization to ensure safe and stable transport.
- Furthermore, the material selection and manufacturing processes of the flatbed undergo rigorous scrutiny and precision control, ensuring long-term durability and structural integrity.
- Loading/Unloading: It acts as a ramp to safely winch and load disabled vehicles onto the truck's deck.
- Towing Preparation: It extends and lowers to the ground to allow for the easy attachment of the truck's under-lift towing equipment to the disabled vehicle.
Products Parameters
|
Chassis Specification |
||
|
Chassis Model |
QL5350 |
|
|
Driving Model |
6X4 |
|
|
Cab |
|
|
|
Dimension |
11500 x 2500 x 3900 mm |
|
|
Wheelbase |
5200+1370 mm |
|
|
Gross vehicle Weight |
35000 kg |
|
|
Front Axle Loading Capacity |
9000 kg |
|
|
Rear Axle Loading Capacity |
13000 kg x2 |
|
|
Axle Number |
3 |
|
|
Engine |
ISUZU diesel engine 6 cylinders in a line, Water cooled, turbocharged, after cooled, cold start. |
|
|
Model: 6WG1-TCG61 |
||
|
Horse power: 460 HP |
||
|
Displacement: 15681 ml |
||
|
Emission standard: Euro 6 |
||
|
Transmission |
Model: FAST Manual Type |
|
|
12 Forward & 2 Reverse |
||
|
Tire |
Front: 385/65R22.5 Rear: 315/80R22.5 |
|
|
10 Pcs with one spare tire |
||
|
Fuel Tank Capacity |
400L |
|
|
Brakes |
Air brake, With ABS |
|
|
Upper Body Specifications |
||
|
Flatbed Platform |
Size: 8000 x 2500 mm |
|
|
Thickness : 6mm checked plate |
||
|
Loading Capacity: 20 Ton |
||
|
Frame: 16 mm Thick manganese plate |
||
|
Winch |
15 Ton |
|
|
Rear Lifting Arm |
10 Ton |
|
|
Box Plate |
Material: Aluminum Alloy |
|
|
Hydraulic Back Platform |
2400 x 2500 mm |
|
|
10Ton Folding Boom Crane Specifications |
||
|
Working Platform |
360°turning (left or right), H-shape legs 360° |
|
|
Max. Lifting Capacity |
Effectively: 4000 kg at 2.5 meters |
|
|
Max. Working Radius |
12.4 meters |
|
|
Max. Lifting Height |
15.4 meters |
|
|
Outrigger |
|
|
Products Video
For quick inquiry, please contact Ms. Hedy He:
WhatsApp/ Wechat: +86 188 2740 1066
Email: hedy@clw-autos.com.
Company Profile
Hubei ChengLi Special Automobile Co.,Ltd,one of branches of CLW group, which was appointed by the Development and Reform Committee of China. Hubei Chengli is a professional company who deal in different kinds of special vehicles, trailers and construction machinery.
Our advantage
- Certificate: ASME, ISO, BV, SGS, CCC etc.
- More than 30 independents workshops for different trucks
- 1000 sets of equipment, 25 assemble lines.
- 8000 staffs including 300 senior engineers and technicians
- 800 kinds of trucks and semi-trailers covering different industry
- 20 years wholesale experience
- Export to 90 countries
- Cooperates with DONGFENG, SINOTRUK, ISUZU, FOTON,FAW,BEIBEN,etc.
Welcome to visit our factory!
